Rockwell Automation Publication 7000L-UM301F-EN-P - March 2020 287
Component Definition and Maintenance Chapter 5
Converter Cabinet Components
Figure 236 - Converter Cabinet Components (4160V AFE shown)
Ground Bus
Isolated Gate Driver
Power Supplies
(IGDPS)
Inverter Modules
Rectifier Modules
Coolant Piping
