266 Rockwell Automation Publication 7000L-UM301F-EN-P - March 2020
Chapter 5 Component Definition and Maintenance
Figure 221 - AFE Control and Cabling Cabinet (with LV Control Panel removed)
Motor Terminals
Line Terminals
Hall-Effect Sensor
Voltage Sensing
Hall-Effect Sensor
Surge Arresters
Current Transformer
Current Transformer
