Component Definition and Maintenance Chapter 5
The following is the list of test points on the DPM.
Table 21 - Test Points on Drive Processor Module
This table defines the states of LED D9 and D11 on the DPM board. D9 is used
for the Inverter side processor and D11 is for the Rectifier side processor. The
other two LEDs (D6 and D7) are the watchdogs for the Inverter and Rectifier
code respectively.
Table 22 - Description of D9 and D11 Function
Diagnostic Test Points on the DPM have a voltage output range of -5 to +5V.
Test points Name Description
DPM-TP1 +1.2V +1.2V DC power supply
DPM-TP2 +1.8V +1.8V DC power supply
DPM-TP3 +2.5V +2.5V DC power supply
DPM-TP4 +3.3V +3.3V DC power supply
DPM-TP5 +5V +5V DC power supply
DPM-TP6 DGND Digital ground
DPM-TP8 ITP1 Digital to Analog output – Assignable diagnostic test point
DPM-TP9 ITP2 Digital to Analog output – Assignable diagnostic test point
DPM-TP10 ITP3 Digital to Analog output – Assignable diagnostic test point
DPM-TP7 ITP4 Digital to Analog output – Assignable diagnostic test point
DPM-TP11 RTP4 Digital to Analog output – Assignable diagnostic test point
DPM-TP12 RTP3 Digital to Analog output – Assignable diagnostic test point
DPM-TP13 RTP2 Digital to Analog output – Assignable diagnostic test point
DPM-TP14 RTP1 Digital to Analog output – Assignable diagnostic test point
Color Rate or Count (Pulse) Meaning
Green 10 Count PreExecution OK
Red .25 Hz No Bootcode
Green .25 Hz No Application
Green .5 Hz Downloading via Serial Port
Green 2 Hz Serial Port Active – ie. Terminal
Green 1 Hz Waiting/Loading Application
Green Solid Operation Running or Successful
Red Solid Operation Failed
Red 2 Count POST – RAM Failed
Red 3 Count POST – NVRAM Failed
Red 4 Count POST – DPRAM Failed
Red 8 Count FPGA Loading Failed
Red 9 Count POST – USART Failed:
1 Green Count = Port 1
2 Green Count = Port 2
