Rockwell Automation Publication 7000L-UM301F-EN-P - March 2020 353
Component Definition and Maintenance Chapter 5
10. Apply control power to the drive. The DPMs are shipped with no
firmware installed, so the drive will automatically go into download mode.
Install firmware in the drive following the guidelines on page 383
.
11. Program the drive. Refer to Technical Data “Medium Voltage AC Drive
Parameters” – Publication 7000-TD002_-EN-P. The parameters should
also be saved to NVRAM and then externally to the drive using the
options described earlier in this section.
Figure 292 - ACB and DPM Replacement
Analog Control Board
(ACB)
ANALOG
CONTROL
BOARD
To Next Page
