Rockwell Automation Allen-Bradley PowerFlex 7000 User Manual

Rockwell Automation Publication 7000L-UM301F-EN-P - March 2020 395
Component Definition and Maintenance Chapter 5
4. The ‘COM1 Properties’ window will appear. Set the port settings as
shown below and then click OK.
Figure 336 - COM1 Properties
5. Close the HyperTerminal program. The following message box will appear.
Figure 337 - Disconnect from HyperTerminal
6. Click Ye s . At this point, you will be prompted to save the session.
Figure 338 - Save Session Parameters
7. Click Ye s to terminate the HyperTerminal program.
