a
Bulletin Number
Code Description
7000A “A” Frame (Air-cooled)
7000 “B” Frame (Air-cooled)
7000L “C” Frame (Liquid-cooled)
b
Service Duty/Altitude Code
Code Description
A Normal Duty, 0...1000 m Altitude. Maximum 40 °C Ambient
B
Normal Duty, 1001...5000 m Altitude
Reduced Ambient (from 40 °C offering)
1001...2000 m = 37.5 °C
2001...3000 m = 35 °C
3001...4000 m = 32.5 °C
4001...5000 m = 30 °C
C Heavy Duty, 0...1000 m Altitude. Maximum 40 °C Ambient
D
Heavy Duty, 1001...5000 m Altitude. Reduced Ambient
(from 40 °C offering) – same as “B” code above
E Normal Duty, 0...1000 m Altitude. Maximum 35 °C Ambient
F
Normal Duty, 1001...5000 m Altitude
Reduced Ambient (from 35 °C offering)
1001...2000 m = 32.5 °C
2001...3000 m = 30 °C
3001...4000 m = 27.5 °C
4001...5000 m = 25 °C
G Heavy Duty, 0...1000 m Altitude. Maximum 35 °C Ambient
J Normal Duty, 0...1000 m Altitude. Maximum 50 °C Ambient
L Heavy Duty, 0...1000 m Altitude. Maximum 50 °C Ambient
N Normal Duty, 0...1000 m Altitude. Maximum 20 °C Ambient
Z Custom Configuration (Contact Factory)
c
Drive Current Rating
(1)
(1) Not all amperages are available at all ambient/altitude configurations.
Code Description Code Description
40 40 Amp 215 215 Amp
46 46 Amp 250 250 Amp
53 53 Amp 285 285 Amp
61 61 Amp 325 325 Amp
70 70 Amp 375 375 Amp
81 81 Amp 430 430 Amp
93 93 Amp 495 495 Amp
105 105 Amp 575 575 Amp
120 120 Amp 625 625 Amp
140 140 Amp 657 657 Amp
160 160 Amp 720 720 Amp
185 185 Amp
d
Enclosure Type
Code Description
D Type 1 w/gasket (IP21)
T Type 1 w/gasket (IP21) – Seismic rated
K Type 12 w/vents and filters (IP42)
U Type 12 w/vents and filters (IP42) – Seismic rated
Position
1234567
7000L A 40 D A RPDTD 1–...etc.
abcdef
