Chapter 2 Drive Installation
Figure 49 - Control and Cabling Cabinet (AFE Rectifier version shown) (with Control Panel
removed)
Hall-effect Sensor
Motor Terminals
Line Terminals
Voltage Sensing
Hall-effect Sensor
Surge Arrestors
Current
Transformer
