Chapter 2 Servo Drive and System Comparisons
Ultra3000 (460V) Drive Dimensions
In Figure 4, xxx is replaced by 030, 050, 100, 150, or 220 to represent the
Ultra3000 3 kW, 5 kW, 10 kW, 15 kW, and 22 kW drives respectively.
Figure 4 - Ultra3000 (460V) Dimensions (Catalog number 2098-DSD-HVxxx-SE)
Table 10 - Ultra3000 (460V) Dimensions 2098-DSD-HVxxx-SE
Ultra3000
Servo Drive Cat. No.
A
mm (in.)
B
mm (in.)
C
mm (in.)
D
mm (in.)
H
mm (in.)
I
mm (in.)
2098-DSD-HV030-SE
2098-DSD-HV050-SE
138.7
5.46)
50.8
(2.0)
18.5
(0.73)
349.3
(13.75)
331.5
(13.05)
360.7
(14.2)
2098-DSD-HV100-SE
2098-DSD-HV150-SE
151.6
(5.97)
25
(0.99)
2098-DSD-HV220-SE
203.2
(8.0)
76.2
(3.0)
25.4
(1.0)
380.4
(14.98)
362.6
14.26)
391.8
(15.43)
225.8
(8.89)
A
C
B
B
D
I
H
242.2
(9.54)
C
B
B
Dimensions are in mm (in.)
