Rockwell Automation Allen-Bradley Ultra3000

58 Rockwell Automation Publication 2198-RM006A-EN-P - December 2020
Appendix C Specifications
The table lists power specifications and requirements for the Ultra3000 230V
drives (2098-DSD-030, -075, and -150).
Attribute 2098-DSD-030 2098-DSD-075 2098-DSD-150
AC input voltage
(1)
100…240V rms, single-phase 100…240V rms, three-phase
AC input frequency 47…63 Hz
Main AC input current
(2) (3)
Nom (rms)
230V AC (0-pk) max inrush
28 A
50 A
30 A
50 A
46 A
68 A
Auxiliary AC input current
115V AC (rms) nom
230V AC (rms) nom
115V AC (0-pk) max inrush
(4)
230V AC (0-pk) max inrush
(4)
1.0 A
0.5 A
47 A
95 A
1.0 A
0.5 A
47 A
95 A
1.0 A
0.5 A
47 A
95 A
Continuous output current (rms) 10.6 A 24.7 A 45.9 A
Continuous output current (0-pk) 15 A 35 A 65 A
Peak output current (rms) 21.2 A 53 A 106 A
Peak output current (0-pk) 30 A 75 A 150 A
Bus capacitance 2820 µF 4290 µF 7520 µF
Internal shunt resistance 35  16.5  9.1 
Shunt on 420V DC 420V DC 420V DC
Shunt off 402V DC 402V DC 402V DC
Bus overvoltage 452V DC 452V DC 452V DC
Internal shunt
Continuous power
Peak power
50 W
4.5 kW
50 W
10 kW
180 W
18 kW
External shunt
Resistance
Continuous power
Peak power
30  (-0/+5%)
2.4 kW
6 kW
16.5  (-0/+5%)
4 kW
10 kW
9  (-0/+5%)
8 kW
19 kW
Energy absorption capability
115V AC input
230V AC input
251 J
139 J
381 J
211 J
669 J
370 J
Continuous power output
115V AC input
230V AC input
1.5 kW
3 kW
—
7.5 kW
—
15 kW
(1) Specification is for nominal voltage. The absolute limits are ±10%, or 88…265V rms.
(2) The 2098-DSD-030x-xx, 2098-DSD-075x-xx, and 2098-DSD-150x-xx (200V-class) drives are limited to one contactor cycle per 2 minutes.
(3) Power initialization requires a short period of inrush current. Dual element time delay (slow blow) fuses are recommended.
(4) 400 µs half wave sine.
