Rockwell Automation Publication 2198-RM006A-EN-P - December 2020 75
Appendix D Interconnect Diagrams
Figure 26 - Kinetix 5300 Drives Power Wiring (Single-phase operation)
L3
L2
L1
2
1
MBRK -
MBRK +
U
V
W
2
1
4
3
2
1
4
3
2
1
MBRK -
MBRK +
DC+
SH
24V_COM
+24V
85…132V AC rms
or 170…253V AC rms
Single-phase Input
Note 1
Bonded Cabinet Ground Bus
Control Power
Connector
Mains AC Input
Connector
* Indicates User Supplied Component
2198-C1004-ERS, 2198-C1007-ERS,
2198-C1015-ERS, 2198-C1020-ERS
Kinetix 5300 Drives
Chassis
Note 4
Customer Supplied
+24V DC
Power Supply *
Motor Brake
Connector
Three-phase
Motor Power
Connections
Note 8
Motor Power
Connector
Cable Shield
Clamp
See Table 53
for note information.
Shunt
Connector
Motor Brake
Connections
Circuit Protection *
Note 2
2198-DBxxx-F
Three-phase
AC Line Filter
Note 3
Internal Shunt
Note 7
PE Ground
Note 6
Note 5
