Backplane Electrical Ratings
Backplane Electrical RatingsBackplane Electrical Ratings
Backplane Electrical Ratings
The following are the voltage and current ratings for the Process and I/O backplanes:
Module
Back-plane Electrical Ratings Input/Output Electrical
Ratings
Voltage (Vdc) Current (mA)
9100 18-32 10.4A (400mA per slot) -
9101 18-32 10.4A (400mA per slot) -
9300 18-32 9.6A (400mA per slot) -
9110 18-32 380 -
9111 18-32 380 -
9401 18-32 260 Input: 18-32Vdc @ 24mA
9402 18-32 260 Input: 0-32Vdc @ 6.5mA
9431 18-32 260 Input: 0-32Vdc @ 6.5mA
9432 18-32 260 Input: 18-32Vdc @ 24mA
9481 18-32 260 Output: 18-32Vdc/0-20mA
9482 18-32 260 Output: 18-32Vdc/0-20mA
9451 18-32 165 Output: 18-32Vdc@0.5A, Pilot
duty 16VA, 1.5A Inrush
9801 18-32 6.5 -
9802 18-32 6.5 -
9803 18-32 6.5 -
9831 18-32 0-24 -
9832 18-32 0-24 -
9833 18-32 0-24 -
9851 18-32 500 -
9852 18-32 500 -
9881 18-32 0-24 -
9882 18-32 0-24 -
