3-2
Document: 553632
(ICSTT-RM448_EN_P) Issue: 08:
System Build Manual (AADvance Controller)
CAUTION Handling Modules Stored at Extreme Temperatures
It is recommended that modules removed from storage should be allowed to
normalize their temperature before installation. This is particularly important
when modules have been stored at very low temperatures where
condensation can occur. Remove the modules and place them in an upright
position and wipe away any condensation that might appear on the modules.
Failure to follow these recommendations could lead to damage to modules or
incorrect operation when installed into a running system.
Install Base Units and termination Assemblies: Enclosure DIN Rail Assembly Method
Install Base Units and termination Assemblies: Enclosure DIN Rail Assembly MethodInstall Base Units and termination Assemblies: Enclosure DIN Rail Assembly Method
Install Base Units and termination Assemblies: Enclosure DIN Rail Assembly Method
For a system build that uses DIN rails do the following:
1) Install the DIN rails.
The AADvance controller will be mounted onto one or more pairs of parallel
DIN rails. For each pair of rails, mount the lower rail with its centre line
101.0mm below the centre line of the upper rail. M5 thread rolling screws are
suitable.
2) Mount power supply units.
To install the power supply units, refer to the instructions supplied with the
units.
3) Mount the T9100 processor base unit
Place the T9100 processor base unit onto the DIN rails and position it
towards the left, leaving space for the T9300 I/O base units to the right.
Secure the processor base unit onto the DIN rails by sliding the retaining lever
(below the base unit) to the left.
4) Mount each T9300 I/O base unit
Place a T9300 I/O base unit onto the DIN rails to the right of the T9100
processor base unit.
Slide the I/O base unit to the left until the joining connectors are fully mated.
insert the retaining clips at the top nd bottom of the base units.
Secure the I/O base unit onto the DIN rails by sliding the retaining lever
(below the base unit) to the left. Then insert the backplane clips into the top
and the bottom slots.
5) Mount end stops onto DIN rails.
Install two end stops onto the upper DIN rail, one at each end of the assembly.
6) Fit termination assemblies.
