Power and External Connector Wiring Details
Power and External Connector Wiring DetailsPower and External Connector Wiring Details
Power and External Connector Wiring Details
External connectors for power, serial data, Ethernet data and the application security
device are connected to the T9100 Processor base unit. The field connections for I/O
data are connected to the Termination Assemblies.
The wiring specifications are as follows:
Table 5:
Table 5: Table 5:
Table 5: Exte
ExteExte
External Connectors
rnal Connectorsrnal Connectors
rnal Connectors
Connector
Function
Location Designation Summary
Specifications
Remarks
Controller power in T9100
processor
base unit
PWR–1,
PWR–2
Two 3-way connectors
Conductor cross section
maximum 3.3mm² (12
AWG)
Stripping length
7mm (9/32 in.)
Wire to screw terminals on
free connectors supplied with
processor base unit
Serial ports T9100
processor
base unit
S1–1, S1–2
S2–1, S2–2
S3–1, S3–2
Six 5-way connectors
Conductor cross section
maximum 1.31mm² (16
AWG)
Stripping length
7mm (9/32 in.)
Wire to screw terminals on
free connectors supplied with
processor base unit
Ethernet ports T9100
processor
base unit
E1–1, E1–2
E2–1, E2–2
E3–1, E3–2
RJ45 socket Use network patch cords (not
supplied)
Field wiring (sensors,
actuators and field
power sources)
I/O
Termination
Assemblies
None Screw terminal blocks
Conductor cross section
maximum 1.31mm² (16
AWG)
Stripping length
6mm (¼ in.)
Wire to screw terminal
blocks on termination
assemblies
Program enable key T9100
processor
base unit
KEY DB9 Plug with detected
circuit
Removable security device
that allows workbench
programming, variable
locking/forcing and AADvance
Discover write access.
Supplied with base unit
Conductor cross sections specified are for stranded and solid conductors, with and
without a ferrule.
Note: The AADvance controller does not provide mechanical support to hold power
or external communications. Mechanical support should be arranged in the design of
the installation, for example through the provision of suitable cable trunking.
