 Tighten the screws with a 2.5mm Allen key.
 Install the cable to the plug assembly and tighten the retaining screws by hand.
2) Connect the free end of the expansion cable to the left hand plug of an I/O base
unit using a cable socket assembly.
 Insert a cable socket assembly into the left hand connector of the T9300
processor base unit.
 Secure the socket assembly by inserting the two M3 socket cap screws.
 Tighten the screws with a 2.5mm Allen key.
 Install the cable to the socket assembly and tighten the retaining screws by
hand.
