3-34
Document: 553632
(ICSTT-RM448_EN_P) Issue: 08:
System Build Manual (AADvance Controller)
and indicates that the module has no hardware faults.
When in the recovery Mode and no faults are present the LED is GREEN
Note:
1. If Healthy is GREEN and all the other indicators are OFF then the
module has failed to boot up
2. If Healthy is GREEN and the Ready and Run are RED then the
module is said to be in its shutdown state ( See topic - Module Shutdown
State and Possible Causes in the Troubleshooting Manual Chap 3).
Ready
Provides an indication of the module's education and synchronisation
status
OFF No power
RED Module is booting up (10 to 20 seconds) or not educated or synchronised
with partners
GREEN Module is educated and synchronised with partners
Flashing GREEN
Education or synchronisation is in progress (may be a very short period of
flashing then Green)
Amber Module is in the Recovery Mode
Run
Provides an indication of the module's application status. Should be the
same for all educated and synchronised processors
OFF No power and stays off while the module is booting up (10 to 20 seconds)
RED Module is not educated/synchronised; No application loaded; The
processor module is in the Recovery Mode and the base level firmware is
running
GREEN The application is present and running
AMBER Module is in the Recovery Mode
or
The application is present but not running, press Fault Reset to start it
running.
System Healthy
Provides an indication of the global health of the system, including all
processors and I/O modules. Must be the same indication for all educated
and synchronized processors
OFF No power and stays off while the module is booting up (10 to 20 seconds)
RED System or module faults present
or the application has stopped running because the module has entered
the Recovery Mode.
GREEN No system or module faults present during normal operation and when in
the recovery Mode.
