4-8
Document: 553632
(ICSTT-RM448_EN_P) Issue: 08:
System Build Manual (AADvance Controller)
Ready GREEN
Run AMBER
Channel 1 – 8 Off
6. Press the Fault Reset button on the processor module and the Run indication goes GREEN.
7. The module will now be on-line with the following status indications:
Healthy GREEN
Ready GREEN
Run GREEN
Channel 1 – 8) Dependent on channel status
8. If the module fails to educate and go on-line replace the module.
Table 11:
Table 11: Table 11:
Table 11: Second or third Module of a Group Installation Procedure
Second or third Module of a Group Installation ProcedureSecond or third Module of a Group Installation Procedure
Second or third Module of a Group Installation Procedure
Step Task
1. This procedure applies to a second or third module of a redundant group.
2 Install the Input/Output Module and turn the locking screw to the lock position.
3. The input module will provide the following status indications:
Healthy GREEN
Ready RED
Run RED
Channel 1 – 8 Off
4. The input module will enter its start up sequence during which the module will educate.
Wait for approximately 3 seconds.
5. The module will now provide the following status indications:
Healthy GREEN
Ready GREEN
Run AMBER
Channel 1 – 8 Off
6. Press the Fault Reset button on the processor module and the Run indication goes GREEN.
7. The module will now be on-line with the following status indications:
Healthy GREEN
Ready GREEN
Run GREEN
Channel 1 – 8) Dependent on channel status
