PowerFlex Digital DC Drive User Manual - Publication 20P-UM001C-EN-P - July 2008
3-38 Programming and Parameters
APPLICATIONS
PID Control
782 [PID Target]
Parameter number to which the PID Output value will be written.
Default: 0 = “Not Used”
Options:
786 [PID Source]
Parameter number from which the PID source value will be read.
Default: 0 “Not Used”
Options:
787 [PID Source Gain]
Gain of the input value to Par 786 [PID Source].
Default:
Min/Max:
1.00
–/+100.00
786
1046 [PID Accel Time]
Ramp acceleration time after the block PID offset.
Default:
Min/Max:
Units:
0.00
0.00 / 900.00
s
1047 [PID Decel Time]
Ramp deceleration time after the block PID offset.
Default:
Min/Max:
Units:
0.00
0.00 / 900.00
s
File Group No.
Parameter Name & Description
See page 3-2 for symbol descriptions
Values
Related
A
0 = “Not Used” 16 = “Reserved” 32 = “UsrDefined13” (Par 516)
1 = “Cur Lim Pos” (Par 8) 17 = “Max Fld Pct” (Par 467) 33 = “UsrDefined14” (Par 517)
2 = “Cur Lim Neg” (Par 9) 18 = “Reserved” 34 = “UsrDefined15” (Par 518)
3 = “Reserved” 19 = “UsrDefined0” (Par 503) 35 = “Load Comp” (Par 698)
4 = “Reserved” 20 = “UsrDefined1” (Par 504) 36 = “Out Volt Lvl” (Par 921)
5 = “TrqRedCurLim” (Par 13) 21 = “UsrDefined2” (Par 505) 37 = “Reserved”
6 = “Torque Ref” (Par 39) 22 = “UsrDefined3” (Par 506) 38 = “Speed Ratio” (Par 1017)
7 = “Trim Torque” (Par 40) 23 = “UsrDefined4” (Par 507) 39 = “Reserved”
8 = “Reserved” 24 = “UsrDefined5” (Par 508) 40 = “Reserved”
9 = “Trim Ramp” (Par 42) 25 = “UsrDefined6” (Par 509) 41 = “Tension Red” (Par 1179)
10 = “Trim Speed” (Par 43) 26 = “UsrDefined7” (Par 510) 42 = “Reserved”
11 = “Reserved” 27 = “UsrDefined8” (Par 511) 43 = “Reserved”
12 = “Reserved” 28 = “UsrDefined9” (Par 512) 44 = “CloseLp Comp” (Par 1208)
13 = “Reserved” 29 = “UsrDefined10” (Par 513) 45 = “Reserved”
14 = “Adaptive Ref” (Par 183) 30 = “UsrDefined11” (Par 514) 46 = “Reserved”
15 = “Reserved” 31 = “UsrDefined12” (Par 515)
A
0 = “Not Used” 16 = “SpdRegOutPct” (Par 236) 32 = “UsrDefined13” (Par 516)
1 = “Cur Lim Pos” (Par 8) 17 = “Max Fld Pct” (Par 467) 33 = “UsrDefined14” (Par 517)
2 = “Cur Lim Neg” (Par 9) 18 = “Fld Ref Pct” (Par 500) 34 = “UsrDefined15” (Par 518)
3 = “CurLimPosOut” (Par 10) 19 = “UsrDefined0” (Par 503) 35 = “Load Comp” (Par 698)
4 = “CurLimNegOut” (Par 11) 20 = “UsrDefined1” (Par 504) 36 = “Out Volt Lvl” (Par 921)
5 = “TrqRedCurLim” (Par 13) 21 = “UsrDefined2” (Par 505) 37 = “Filt Trq Cur” (Par 928)
6 = “Torque Ref” (Par 39) 22 = “UsrDefined3” (Par 506) 38 = “Speed Ratio” (Par 1017)
7 = “Trim Torque” (Par 40) 23 = “UsrDefined4” (Par 507) 39 = “Spd Draw Out” (Par 1018)
8 = “TorqueReg In” (Par 41) 24 = “UsrDefined5” (Par 508) 40 = “Roll Diam” (Par 1154)
9 = “Trim Ramp” (Par 42) 25 = “UsrDefined6” (Par 509) 41 = “Tension Red” (Par 1179)
10 = “Trim Speed” (Par 43) 26 = “UsrDefined7” (Par 510) 42 = “Torq Cur Pct” (Par 1193)
11 = “Ramp In” (Par 110) 27 = “UsrDefined8” (Par 511) 43 = “Ten Ref Pct” (Par 1194)
12 = “Ramp Out” (Par 113) 28 = “UsrDefined9” (Par 512) 44 = “CloseLp Comp” (Par 1208)
13 = “Speed Reg In” (Par 118) 29 = “UsrDefined10” (Par 513) 45 = “Actual Comp” (Par 1213)
14 = “Adaptive Ref” (Par 183) 30 = “UsrDefined11” (Par 514) 46 = “W Reference” (Par 1217)
15 = “Arm Cur Pct” (Par 199) 31 = “UsrDefined12” (Par 515)
A
A
A
