PowerFlex Digital DC Drive User Manual - Publication 20P-UM001C-EN-P - July 2008
Programming and Parameters 3-39
APPLICATIONS
PID Control
1254 [PID Error Gain]
Gain percentage of Par 759 [PID Error].
Default:
Min/Max:
Units:
1.005
0.000 / 32.010
%
759
1258 [Enable PID]
Enables/Disables both the PI and PD portions of the PID regulator.
Default:
Options:
0 =
0 =
1 =
“Disabled”
“Disabled”
“Enabled”
Scale Blocks
484
553
1218
1227
1236
1245
[Scale1 Input]
[Scale2 Input]
[Scale3 Input]
[Scale4 Input]
[Scale5 Input]
[Scale6 Input]
Parameter number from which the value is read and used as the input
quantity to the Scale block. Refer to the Scale Blocks block diagram
on page D-18
for more information.
Default:
Min/Max:
0
0 / 1408
485
554
1219
1228
1237
1246
[Scale1 Output]
[Scale2 Output]
[Scale3 Output]
[Scale4 Output]
[Scale5 Output]
[Scale6 Output]
Parameter number to which the value of the Scale block output is
written. Refer to the Scale Blocks
block diagram on page D-18 for
more information.
Default:
Min/Max:
0
0 / 1408
486
555
1220
1229
1238
1247
[Scale1 Mul]
[Scale2 Mul]
[Scale3 Mul]
[Scale4 Mul]
[Scale5 Mul]
[Scale6 Mul]
Multiplier of the input quantity (after a possible limitation). Resolution:
5 digits. Refer to the Scale Blocks block diagram on page D-18 for
more information.
Default:
Min/Max:
1.00
–/+10000.00
487
556
1221
1230
1239
1248
[Scale1 Div]
[Scale2 Div]
[Scale3 Div]
[Scale4 Div]
[Scale5 Div]
[Scale6 Div]
Divisor, through which it is possible to divide the input quantity already
multiplied and limited. Resolution: 5 digits. Refer to the Scale Blocks
block diagram on page D-18
for more information.
Default:
Min/Max:
1.00
–/+10000.00
488
557
1222
1231
1240
1249
[Scale1 In Max]
[Scale2 In Max]
[Scale3 In Max]
[Scale4 In Max]
[Scale5 In Max]
[Scale6 In Max]
Maximum limit of the input quantity. Resolution: 5 digits. Refer to the
Scale Blocks
block diagram on page D-18 for more information.
Default:
Min/Max:
0.00
– 2
31
/ +2
31
– 1
489
558
1223
1232
1241
1250
[Scale1 In Min]
[Scale2 In Min]
[Scale3 In Min]
[Scale4 In Min]
[Scale5 In Min]
[Scale6 In Min]
Minimum limit of the input quantity. Resolution: 5 digits. Refer to the
Scale Blocks
block diagram on page D-18 for more information.
Default:
Min/Max:
0.00
– 2
31
/ +2
31
– 1
File Group No.
Parameter Name & Description
See page 3-2 for symbol descriptions
Values
Related
A
A
A
A
A
A
A
A
