PowerFlex Digital DC Drive User Manual - Publication 20P-UM001C-EN-P - July 2008
Programming and Parameters 3-45
APPLICATIONS
Winder Functions
1215 [Speed Demand En]
Enables/Disables the speed reference calculation for the Torque
Winder application.
Default:
Options:
0 =
0 =
1 =
“Disabled”
“Disabled”
“Enabled”
1216 [Spd match torque]
Sets the torque current during the launching and change phase.
Default:
Min/Max:
Units:
100
0 / 200
%
1217 [W Reference]
Angular speed reference.
Note: This parameter can be assigned to an analog output; 10V =
100% of Par 45 [Max Ref Speed].
Default:
Min/Max:
Units:
Read Only
–/+8192
RPM
1160
1255 [Jog TW Speed]
Torque Winder jog reference. The parameter is entered as a
percentage of Par 1160 [Line Speed Pct].
Default:
Min/Max:
Units:
0
0 / 100
%
1160
1256 [Jog TW Enable]
Enables/Disables the Torque Winder jog function.
Note: This parameter can be assigned to a digital input.
Default:
Options:
0 =
0 =
1 =
“Disabled”
“Disabled”
“Enabled”
1284 [Ref Spd Source]
Number of the line speed reference sampling parameter (used for
inertia compensation and line speed reference).
Default:
Min/Max:
0
0 / 65535
1285 [Ref Speed Gain]
Gain value for the line speed reference. The value of this parameter
depends on the value of Par 1284 [Ref Spd Source]. The value of [Ref
Speed Gain] is used to obtain a line speed reference = 100% at its
maximum value.
Default:
Min/Max:
0
0 / 32767
1284
1286 [Ref Line Speed]
Line speed percentage.
Default:
Min/Max:
Units:
Read Only
0.00 / 150.00
%
1287 [Static F Zero]
Enables/Disables friction compensation.
• "Enabled" = The fiction compensation value is added to all speed
values.
• "Disabled" = The static friction compensation value is added to Par
1286 [Ref Line Speed] = 1.5%.
Default:
Options:
0 =
0 =
1 =
“Disabled”
“Disabled”
“Enabled”
1286
File
Group
No.
Parameter Name & Description
See page 3-2 for symbol descriptions
Values
Related
A
A
A
A
A
A
A
A
A
