PowerFlex Digital DC Drive User Manual - Publication 20P-UM001C-EN-P - July 2008
3-44 Programming and Parameters
APPLICATIONS
Winder Functions
1196 [Spd Match Acc]
Motor acceleration time during the launching phase.
Default:
Min/Max:
Units:
83.88
0.30 / 300.00
s
1197 [Spd Match Dec]
Motor deceleration time. If the motor decelerates during the launching
phase a stop command is issued.
Default:
Min/Max:
Units:
83.88
0.30 / 300.00
s
1198 [Offs Accel Time]
Ramp time for the initial phase when the machine is stopped. It refers
to Par 45 [Max Ref Speed].
Default:
Min/Max:
Units:
83.88
0.30 / 300.00
s
1199 [W Offset]
Speed reference offset for the initial phase of the winder/unwinder
when the line is stopped.
Default:
Min/Max:
Units:
0
0 / 1000
RPM
1200 [Spd Match Gain]
Speed reference gain during the launching phase. 100% corresponds
to a peripheral speed equal to the line speed.
Default:
Min/Max:
Units:
100
0 / 150
%
1201 [Winder Side]
Selection of the winding/unwinding side.
“0” = Up
“1” = Down
Note: This parameter can be assigned to a digital input.
Default:
Min/Max:
0
0 / 1
1202 [W Gain]
Sets the speed reference gain used to saturate the speed loop. This
parameter is a percentage of the increasing/decreasing value of the
angular speed reference.
Default:
Min/Max:
Units:
0
0 / 100
%
1203 [Spd Match Compl]
Indicates a completed launching ramp. If this parameter is assigned
to a programmed digital output, it can be used to indicate that the coil
can be changed.
“1” = Launching ramp completed
“0” = Launching ramp not completed
Default:
Min/Max:
Read Only
0 / 32767
1204 [Line Spd Source]
Number of the sampling parameter for the line speed.
Default:
Min/Max:
0
0 / 65535
1208 [Close Loop Comp]
Active compensation status (output of the PID regulator).
Default:
Min/Max:
Read Only
– / +32767
1209 [Torque Winder En]
Enables/disables the center winder function.
Default:
Options:
0 =
0 =
1 =
“Disabled”
“Disabled”
“Enabled”
1210 [W Target]
Parameter number of the speed reference address.
Default:
Min/Max:
0
0 / 65535
1213 [Actual Comp]
Active compensation status (sums up the static, dynamic and inertial
frictions) as a percentage of the drive rated current.
Note: This parameter can be assigned to an analog output.
Default:
Min/Max:
Units:
Read Only
–/+200
%
1214 [Closed Loop En]
Enables/Disables closed loop tension control (used with a load cell).
Default:
Options:
0 =
0 =
1 =
“Disabled”
“Disabled”
“Enabled”
File
Group
No.
Parameter Name & Description
See page 3-2 for symbol descriptions
Values
Related
A
A
A
A
A
A
A
A
A
A
A
A
A
A
