PowerFlex Digital DC Drive User Manual - Publication 20P-UM001C-EN-P - July 2008
Programming and Parameters 3-47
UTILITY
Diagnostics
346 [Torque Positive]
Indicates whether the drive is operating with a positive torque
reference.
• 1 “Active” = The drive is operating with a positive torque reference.
The motor is accelerating in the forward direction or decelerating in
the negative direction and Par 20 [Ramp Delay] has timed out.
• 0 “Not Active” = The drive is not operating with a positive torque
reference.
Note: This parameter can be assigned to a digital output.
Default:
Min/Max:
Read Only
0 / 1
20
347 [Torque Negative]
Indicates whether the drive is operating with a negative torque
reference.
• 1 “Active” = The drive is operating with negative torque reference.
The motor is accelerating in the reverse direction or decelerating in
the forward direction and Par 20 [Ramp Delay] has timed out.
• 0 “Not Active” = The drive is not operating with negative torque
reference.
Note: This parameter can be assigned to a digital output and is used
for four quadrant drives only.
Default:
Min/Max:
Read Only
0 / 1
20
349 [CurrLimit Active]
Indicates whether or not the drive is working within the set current
limits.
• 1 “Active” = The drive is currently in a current limited state.
• 0 “Not Active” =The drive is not in a current limited state.
Note: This parameter is assigned to digital output 4 (Par 148 [Digital
Out4 Sel]) by default.
Default:
Min/Max:
Read Only
0 / 1
372 [Spd Limit Active]
Indicates whether the current speed reference value is limited by the
defined minimum and maximum limit values.
• 1 “Active” = The reference value is currently limited since the value
entered is out of range of the limit values defined.
• 0 “Not Active” = The reference value is within the defined limit
values.
Note: This parameter can be assigned to a digital output.
Default:
Min/Max:
Read Only
0 / 1
File
Group
No.
Parameter Name & Description
See page 3-2 for symbol descriptions
Values
Related
A
A
To Next Page
