PowerFlex Digital DC Drive User Manual - Publication 20P-UM001C-EN-P - July 2008
3-48 Programming and Parameters
UTILITY
Diagnostics
381 [Drive Status 1]
Present operating condition of the drive.
Bit 0 “Ready” - When set (= “1”), the drive is ready
Bit 1 “Active” - When set, the drive is active
Bit 2 “Command Dir” - The direction of commanded rotation, 0 = Reverse, 1 = Forward
Bit 3 “Actual Dir” - The actual direction of the motor, 0 = Reverse, 1 = Forward
Bit 4 “Accelerating” - When set, the drive is accelerating
Bit 5 “Decelerating” - When set , the drive is decelerating
Bit 6 “Alarm” - When set, the drive is in an alarm state
Bit 7 “Fault” - When set, the drive is faulted
Bit 8 “At Speed” -When set, the drive is at the commanded speed
Bit 9 - 11 “Local ID 0-2”
(1)
Bit 12-15 “Spd Ref ID 0-3”
(2)
Read Only
382 [Drive Status 2]
Present operating condition of the drive.
Bit 0 “Ready” - When set (= “1”), the drive is ready
Bit 1 “Active” - When set, the drive is active
Bit 2 “Running” - When set, the drive is running
Bit 3 “Jogging” - When set, the drive is being jogged
Bit 4 “Stopping” - When set, the drive is stopping
Bit 6 “Auto Tuning” - When set, the drive is auto tuning
Read Only
File Group No.
Parameter Name & Description
See page 3-2 for symbol descriptions
Values
Related
Spd Ref ID 3
(2)
Spd Ref ID 2
(2)
Spd Ref ID 1
(2)
Spd Ref ID 0
(2)
Local ID 2
(1)
Local ID 1
(1)
Local ID 0
(1)
At Speed Faulted Alarm Decelerating Accelerating Actual Dir Command Dir Active Ready
Default
0000001000001101
Bit
1514131211109876543210
(2)
Bits
Description
(1)
Bits
Description15 14 13 12 11 10 9
0000Spd Ref A Auto 0 0 0 Port 0 (TB)
0001Spd Ref B Auto 0 0 1 DPI Port 1
0010Preset Spd 2 Auto 0 1 0 DPI Port 2
0011Preset Spd 3 Auto 0 1 1 DPI Port 3
0100Preset Spd 4 Auto 1 0 0 DPI Port 4
0101Preset Spd 5 Auto 1 0 1 DPI Port 5
0110Preset Spd 6 Auto 1 1 0 DPI Port 6
0111Preset Spd 7 Auto 1 1 1 No Local Control
1000TB Manual
1001DPI Port 1 Manual
1010DPI Port 2 Manual
1011DPI Port 3 Manual
1100DPI Port 4 Manual
1101DPI Port 5 Manual
1110DPI Port 6 Manual
1111Jog Ref
Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Auto Tuning Curr Limit Stopping Jogging Running Active Ready
Default
xxxxxxxx00000001
Bit
1514131211109876543210
