Programming and Parameters 3-67
PowerFlex Digital DC Drive User Manual - Publication 20P-UM001C-EN-P - July 2008
INPUT / OUTPUT
Digital Inputs
564 [Dig In Status]
Status of the digital inputs.
Read Only
565
566
567
568
569
570
571
572
573
574
575
576
[Dig In Term 1]
[Dig In Term 2]
[Dig In Term 3]
[Dig In Term 4]
[Dig In Term 5]
[Dig In Term 6]
[Dig In Term 7]
[Dig In Term 8]
[Dig In Term 9]
[Dig In Term 10]
[Dig In Term 11]
[Dig In Term 12]
Status of the digital inputs.
0 = Low
1 = High
Default:
Min/Max:
Read Only
0 / 1
1276
1277
1278
1279
1280
1281
1282
1283
1387
1388
1389
1390
[Inversion In 1]
[Inversion In 2]
[Inversion In 3]
[Inversion In 4]
[Inversion In 5]
[Inversion In 6]
[Inversion In 7]
[Inversion In 8]
[Inversion In 9]
[Inversion In 10]
[Inversion In 11]
[Inversion In 12]
inverts the digital input signal.
Default:
Options:
0
0 =
1 =
“Disabled”
“Disabled”
“Enabled”
1391 [ContactorControl]
Selects the type of contactor to be controlled by the drive. Either
style of contactor (AC or DC) can be used, with or without
dynamic braking (DB) contactor.
• “AC Cntctr” indicates an AC contactor is used
• “AC Cntctr+DB” indicates that an AC contactor and dynamic
brake resistor is used
• “DC Cntctr” indicates a DC contactor is used
• “DC Cntctr+DB” indicates that a DC contactor and dynamic
brake resistor is used
The type of control selected determines how many I/O points
will be required for contactor control and status.
• “AC Cntctr” or “DC Cntctr” = 1 (relay) digital output, 1 digital
input is used
• “AC Cntctr+DB” or “DC Cntctr+DB” = 2 (relay) digital outputs,
1 digital input is used
Note: Options 1 and 2 changed from “Contactor” and
“Contactor+DB” to “AC Cntctr” and AC Cntctr+DB”, respectively,
and options 3 and 4 added with firmware version 2.001.
Default:
Options:
1 =
0 =
1 =
2 =
3 =
4 =
“AC Cntctr”
“None”
“AC Cntctr”
“AC Cntctr+DB”
“DC Cntctr”
“DC Cntctr+DB”
File Group No.
Parameter Name & Description
See page 3-2 for symbol descriptions
Values
Related
Reserved Reserved Reserved Reserved Digital In12 Digital In11 Digital In10 Digital In9 Digital In8 Digital In7 Digital In6 Digital In5 Digital In4 Digital In3 Digital In2 Digital In1
Default
xxxx000000000000
Bit
1514131211109876543210
A
A
