PowerFlex Digital DC Drive User Manual - Publication 20P-UM001C-EN-P - July 2008
A-8 Supplemental Drive Information
Table A.B Recommended AC Input Line Fuses - 460V AC Input Frame A and B
(Regenerative and Non-Regenerative Drives)
Table A.C Recommended Armature DC Output Fuses - 230V AC Input Frame A and B
(Regenerative Drives Only)
Frame
Drive
Current
Rating
Code
DC
Amps
AC
Line
Amps
Fuse Code FS1 (See Figure A.3 on page A-7
)
Bussmann Ferraz Shawmut (Gould Shawmut)
Ferrule FWP
Type
Ferrule
Fuse Block
North American
FWP Type
North
American
Fuse Block
Ferrule A70QS
Type
North American
A70P / A70QS Type
A 4P1 4.1 3.3 FWP-10A14F CH143D FWP-10B – A70QS10-14F A70P10-4
6P0 6 4.9 FWP-10A14F FWP-10B – A70QS10-14F A70P10-4
010 10 8.2 FWP-20A14F FWP-20B – A70QS20-14F A70P25-4
014 14 11.4 FWP-25A14F FWP-25B – A70QS25-14F A70P25-4
019 19 15.5 FWP-25A14F FWP-25B – A70QS25-14F A70P25-4
027 37 22.1 FWP-40A22F CH223D FWP-40B – A70QS40-22F A70QS40-4
035 35 28.6 FWP-63A22F FWP-60B – A70QS63-22F A70QS60-4
045 45 36.8 FWP-80A22F FWP-80B – A70QS80-22F A70QS80-4
052 52 42.5 FWP-80A22F FWP-80B – A70QS80-22F A70QS80-4
073 73 59.6 – – FWP-100A ST14 – A70QS100-4K
086 86 70.3 – – FWP-150A – A70QS150-4K
100 100 81.7 – – FWP-175A – A70QS175-4K
129 129 105.4 – – FWP-175A – A70QS175-4K
B 167 167 136.4 – – FWP-300A – A70QS300-4
207 207 169.1 – – FWP-350A – A70QS350-4
250 250 204.3 – – FWP-400A ST38-72612 – A70QS400-4
330 330 269.6 – – FWP-600A – A70QS600-4K
412 412 336.6 – – FWP-600A – A70QS600-4
Frame
Drive
Current
Rating
Code
DC
Amps
AC
Line
Amps
Fuse Code FS2
(1)
(See Figure A.3 on page A-7)
Bussmann Ferraz Shawmut (Gould Shawmut)
Ferrule FWP
Type
Ferrule
Fuse Block
North American
FWP Type
North
American
Fuse Block
Ferrule
A70QS Type
North American
A70P / A70QS Type
A 7P0 7 5.7 FWP-15A14F CH142D FWP-15B – A70QS16-14F A70P15-4
9P0 9 7.4 FWP-20A14F FWP-20B – A70QS20-14F A70P20-4
012 12 9.8 FWP-25A14F FWP-25B – A70QS25-14F A70P25-4
020 20 16 FWP-40A14F FWP-40B – A70QS40-14F A70QS40-4
029 29 24 FWP-63A22F CH222D FWP-60B – A70QS63-22F A70QS60-4
038 38 31 FWP-80A22F FWP-80B – A70QS80-22F A70QS80-4
055 55 45 – – FWP-125A ST14 – A70QS125-4K
073 73 60 – – FWP-150A – A70QS150-4K
093 93 76 – – FWP-200A – A70QS200-4K
110 110 90 – – FWP-225A – A70QS250-4
B 146 146 119 – – FWP-300A – A70QS300-4
180 180 147 – – FWP-350A A70QS350-4
218 218 178 – – FWP-450A ST38-72612 – A70QS450-4
265 265 217 – – FWP-600A – A70QS600-4K
360 360 294 – – FWP-700A – A70QS700-4
434 434 355 – – FWP-900A – – A70P900-4
(1)
Required on four quadrant drives only, highly recommended on two quadrant drives.
