PowerFlex Digital DC Drive User Manual - Publication 20P-UM001C-EN-P - July 2008
Supplemental Drive Information A-9
Table A.D Recommended Armature DC Output Fuses - 460V AC Input Frame A and B
(Regenerative Drives Only)
Table A.E Recommended Field Circuit Fuses - 230V AC Input Frame A and B
(Regenerative and Non-Regenerative Drives)
Frame
Drive
Current
Rating
Code
DC
Amps
AC
Line
Amps
Fuse Code FS2
(1)
(See Figure A.3 on page A-7)
Bussmann Ferraz Shawmut (Gould Shawmut)
Ferrule FWP
Type
Ferrule
Fuse Block
North American
FWP Type
North
American
Fuse Block
Ferrule
A70QS Type
North American
A70P / A70QS Type
A 4P1 4.1 3.3 FWP-10A14F CH142D FWP-10B – A70QS10-14F A70P10-4
6P0 6 4.9 FWP-15A14F FWP-15B – A70QS16-14F A70P15-4
010 10 8.2 FWP-20A14F FWP-20B – A70QS20-14F A70P20-4
014 14 11.4 FWP-30A14F FWP-30B – A70QS32-14F A70P30-4
019 19 15.5 FWP-40A14F FWP-40B – A70QS40-14F A70QS40-4
027 37 22.1 FWP-63A22F CH222D FWP-60B – A70QS63-22F A70QS60-4
035 35 28.6 FWP-80A22F FWP-70B – A70QS80-22F A70QS70-4
045 45 36.8 FWP-100A22F FWP-90B – – A70QS90-4
052 52 42.5 FWP-100A22F FWP-100B – – A70QS100-4
073 73 59.6 – – FWP-150A ST14 – A70QS150-4K
086 86 70.3 – – FWP-175A – A70QS175-4K
100 100 81.7 – – FWP-200A – A70QS200-4K
129 129 105.4 – – FWP-250A – A70QS250-4
B 167 167 136.4 – – FWP-350A – A70QS350-4
207 207 169.1 – – FWP-400A – A70QS400-4
250 250 204.3 – – FWP-500A ST38-72612 – A70QS500-4K
330 330 269.6 – – FWP-700A – A70QS700-4
412 412 336.6 – – FWP-800A – A70QS800-4
(1)
Required on four quadrant drives only, highly recommended on two quadrant drives.
Frame
Drive
Current
Rating
Code
Field
Amps Type
Fuse Code FS3
(1)
(SeeFigure A.3 on page A-7, Figure A.4 on
page A-10 and Figure A.5 on page A-11 for location)
(1)
Internal fuses - provided with the drive.
Bussmann
Ferraz Shawmut
(Gould Shawmut) SIBA
A 7P0 10 6 x 32 mm FWH-016A6F E085449 70 125 40.16
9P0
012
020
029
038
055
073 14
093
110
B 146 20 10 x 38 mm FWC-25A10F A60Q25-2 60 033 05.25
180
218
265
360
434
