PowerFlex Digital DC Drive User Manual - Publication 20P-UM001C-EN-P - July 2008
A-10 Supplemental Drive Information
Table A.F Recommended Field Circuit Fuses - 460V AC Input Frame A and B
(Regenerative and Non-Regenerative Drives)
Figure A.4 Frame A Field Circuit Fuses Location
Frame
Drive
Current
Rating
Code
Field
Amps Type
Fuse Code FS3
(1)
(SeeFigure A.3 on page A-7, Figure A.4 below
and Figure A.5 on page A-11
for location)
(1)
Internal fuses - provided with the drive.
Bussmann
Ferraz Shawmut
(Gould Shawmut) SIBA
A 4P1 10 6 x 32 mm FWH-016A6F E085449 70 125 40.16
6P0
010
014
019
027
035
045
052
073 14
086
100
129
B 167 20 10 x 38 mm FWC-25A10F A60Q25-2 60 033 05.25
207
250
330
412
Bottom View of Drive without Fan
Field circuit fuses
Bottom View of Drive with Fan
