PowerFlex Digital DC Drive User Manual - Publication 20P-UM001C-EN-P - July 2008
3-12 Programming and Parameters
MONITOR
Speed Meters
924 [Actual Speed]
Filtered value of Par 122 [Spd Feedback].
Note: This parameter can be assigned to an analog output.
Default:
Min/Max:
Units:
Read Only
–/+32766
RPM
121
1018 [Speed Draw Out]
Speed draw output value.
Note: This parameter can be assigned to an analog output.
Default:
Min/Max:
Units:
Read Only
–/+ Par 45 [Max Ref Speed]
1
RPM
45
(1)
The value of [Max Ref Speed] cannot exceed 8192 RPM.
1019 [Spd Draw Out Pct]
Speed value as a percentage of Par 45 [Max Ref Speed].
Default:
Min/Max:
Units:
Read Only
–/+100.00
%
45
1408 [Tachometer Speed]
Actual speed measured by the DC analog tachometer.
Default:
Min/Max:
Units:
Read Only
–/+32770
RPM
Current Meters
10 [Cur Lim Pos Out]
Displays the value of the current limit for the positive torque
direction, expressed as a percentage of the value in Par 179
[Nom Mtr Arm Amps].
Default:
Min/Max:
Units:
Read Only
0 / 200
%
179
11 [Cur Lim Neg Out]
Displays the value of the current limit for the negative torque
direction, expressed as a percentage of the value in Par 179
[Nom Mtr Arm Amps].
Default:
Min/Max:
Units:
Read Only
0 / 200
%
179
41 [Current Reg In]
Total current reference value expressed as a percentage of the
value in Par 179 [Nom Mtr Arm Amps].
Note: This parameter can be assigned to an analog output.
Default:
Min/Max:
Units:
Read Only
–/+200
%
179
199 [Arm Current Pct]
Armature current expressed as a percentage of the value in Par
179 [Nom Mtr Arm Amps].
Note: This parameter is assigned to analog output 2 (Terminals
23 and 24, Par 67 [Anlg Out2 Sel]) by default, but can be
assigned to any analog output.
Default:
Min/Max:
Units:
Read Only
–/+250
%
179
200 [Arm Current]
Armature current in Amperes.
Default:
Min/Max:
Units:
Read Only
–/+2.5 x [Nom Mtr Arm Amps]
A
234 [Fld Current Pct]
Field current (present value) as a percentage of Par 280 [Nom
Mtr Fld Amps].
Note: This parameter can be assigned to an analog output.
Default:
Min/Max:
Units:
Read Only
0.00 / 100.00
%
280
236 [Spd Reg Out Pct]
Output value of the speed regulator used as the reference for
the current regulator.
Note: By default, this parameter is linked to Par 39 [Torque Ref].
Default:
Min/Max:
Units:
Read Only
–/+200
%
39
351 [Field Current]
Present value of the field current. The value of this parameter
equals the value of Par 468 [Min Fld Curr Pct] when Par 499
[Field Economy En] = 1 “Enabled” and Field Economy becomes
active.
Default:
Min/Max:
Units:
Read Only
0.00 / 99.90
A
500 [Field Ref Pct]
Field current (reference) as a percentage of Par 280 [Nom Mtr
Fld Amps].
Note: This parameter can be assigned to an analog output.
Default:
Min/Max:
Units:
Read Only
0.00 / 100.00
%
280
928 [Filt TorqCur Pct]
Percent filtered value of Par 199 [Arm Current Pct].
Note: This parameter can be assigned to an analog output.
Default:
Min/Max:
Units:
Read Only
–/+200
%
1193
File
Group
No.
Parameter Name & Description
See page 3-2 for symbol descriptions
Values
Related
