PowerFlex Digital DC Drive User Manual - Publication 20P-UM001C-EN-P - July 2008
Programming and Parameters 3-13
MONITOR
Drive Data
57 [FaultCode]
A code that represents the fault that tripped the drive. Refer to
Fault Descriptions on page 4-4 for a list of fault codes and
descriptions.
Default:
Min/Max:
Read Only
0 / 65535
233 [Output Voltage]
Armature Voltage U
dA
in V
AV
.
Note: This parameter can be assigned to an analog output.
Default:
Min/Max:
Units:
Read Only
-/+999.00
Vdc
235 [Elapsed Lifetime]
Shows the operating time of the drive. This parameter counts
the time for which the drive is energized (even if the drive is
disabled).
Default:
Min/Max:
Units:
Read Only
0.00 / 65540.00
H.m
300 [Drive Type]
Displays of the drive type.
“10” = Non-Regenerative
“11” = Regenerative
Default:
Min/Max:
Read Only
10 / 11
331 [Software Version]
Displays the software version number active in the drive.
Default:
Min/Max:
Read Only
1.00 / 999.00
465 [Drive Size]
Armature current rating (as indicated by the configuration of DIP
switch S15 on the Control board).
Note: S15 is set to the appropriate value at the factory. However,
if the Control board was supplied as a replacement part, S15
must be manually set to the appropriate drive size. Refer to DIP
Switch and Jumper Settings on page 1-32.
Default:
Min/Max:
Units:
Read Only
0 / Based on drive current rating
A
466 [AC Line Voltage]
AC input voltage.
Default:
Min/Max:
Units:
Read Only
0 / 960
Vac
588 [AC Line Freq]
AC input frequency.
Default:
Min/Max:
Units:
Read Only
0.00 / 70.00
Hz
1052 [Output Power]
Output power.
Note: This parameter can be assigned to an analog output.
Default:
Min/Max:
Units:
Read Only
0.00 / 9999.99
kW
File Group No.
Parameter Name & Description
See page 3-2 for symbol descriptions
Values
Related
