4.2.5 Specification of HD102
Table 4-4. Specification for HD102
Item
Figure
Storage Temperature
-35~70°C
Storage Humidity 25~50%
Operating Temperature
-20~40°C
-20~60°C
Operating Humidity
10~90%
Power In 100-240V AC 50/60Hz
Dimension
L485 x W320 x H45mm, 1U
Net Weight (Processor Only)
3.2kg
Gross Weight 5.1kg
Nominal pixel capacity
~2.3M pixels (Equivalent to 1920 px x 1200 px @60 Hz)
Input
Input Ports DVI * 1, HDMI * 1
DVI In/Loop
Max. Input/Loop Width
4095 px (4095 x 562 @60 Hz)
Max. Input/Loop Height
1600 px (1440 x 1600 @60 Hz)
DVI-I (Dual-Link, Female).
VESA Standard (1080p input supported)
HDMI In/Loop
Max. Input/Loop Width
4095 px (4095 x 562 @60 Hz)
Max. Input/Loop Height
1600 px (1440 x 1600 @60 Hz)
EIA/CEA-861 Standard. HDMI1.4 - Type-A.
HDCP1.4 supported (HDMI In Only).
Output
Output Ports
Gigabit Ethernet port * 4, available for Neutrik NE8MC RJ45
connector or RJ45 terminator
Max. Output Per Port
655,000 px @60 Hz
Max. Output Width
DVI Input
HDMI Input
4095 px 4,095 px
Max. Output Height
DVI Input & HDMI Input
1,600 px
Ethernet Output
Regular Mode
Low Latency Enabled
Max. Output
655,000 px @60 Hz
Max. Width 4,095 px 512 px
Max. Height
1,600 px
Fiber Output
2.5G single-mode fiber * 2, LC connector (transceiver module
needed). Max. distance for 15km.
Control
USB
USB 2.0 Type B (female) * 2, for PC-processor control;
USB 2.0 Type A (female) * 1, for processors cascade.
Network Port Fast Ethernet port (100Mbit)
DMX
DMX512, XLR5 Connectors
Genlock
Genlock In/Loop, BNC Connectors. Tri-level Sync.
