9.4 Maximum Loading Capacity of One Output Port of HD102
Table 9-5. Maximum loading of one output port of HD102
Refresh Rate
Product
60Hz 50Hz
BO2 (176 x 176 px) 17 pcs 20 pcs
BO3 (144 x 144 px) 25 pcs 30 pcs
BP3 (128 x 128 px) 32 pcs 38 pcs
BP5 (96 x 96 px) 57 pcs 68 pcs
MC5H (104 x 104 px) 49 pcs 58 pcs
MC7H (80 x 80 px) 82 pcs 98 pcs
MC9H 129 pcs 154 pcs
MC12H 230 pcs 276 pcs
MC18H 512 pcs 512 pcs
HY15 164 pcs 196 pcs
HY15S 512 pcs 512 pcs
HY18 256 pcs 307 pcs
CB5 24 pcs 28 pcs
CB8 50 pcs 60 pcs
BM7 82 pcs 98 pcs
BM15 164 pcs 196 pcs
