MC9S08QE128 MCU Series Reference Manual, Rev. 2
Freescale Semiconductor 19
Chapter 1
Device Overview
The MC9S08QE128, MC9S08QE96, and MC9S08QE64 are members of the low-cost, low-power,
high-performance HCS08 Family of 8-bit microcontroller units (MCUs). All MCUs in the family use the
enhanced HCS08 core and are available with a variety of modules, memory sizes, memory types, and
package types.
1.1 Devices in the MC9S08QE128 Series
Table 1-1 summarizes the feature set available in the MC9S08QE128 Series of MCUs.
t
Table 1-1. MC9S08QE128 Series Features by MCU and Package
Feature MC9S08QE128 MC9S08QE96 MC9S08QE64
Flash size (bytes) 131,072 98,304 65,536
RAM size (bytes) 8064 6016 4096
Pin quantity 80 64 48 44 80 64 48 44 64 48 44 32
ACMP1 yes
ACMP2 yes
ADC channels 24 22 10 10 24 22 10 10 22 10 10 10
DBG yes
ICS yes
IIC1 yes
IIC2 yes yes no no yes yes no no yes no no no
IRQ yes
KBI 16 16 16 16 16 16 16 16 16 16 16 12
Port I/O
1
1
Port I/O count does not include the input only PTA5/IRQ/TPM1CLK/RESET or the output
only PTA4/ACMP1O/BKGD/MS.
70 54 38 34 70 54 38 34 54 38 34 26
RTC yes
SCI1 yes
SCI2 yes
SPI1 yes
SPI2 yes
TPM1 channels 3
TPM2 channels 3
TPM3 channels 6
XOSC yes
