Development Support
MC9S08QE128 MCU Series Reference Manual, Rev. 2
314 Freescale Semiconductor
Table 17-1. BDC Command Summary
Command
Mnemonic
Active BDM/
Non-intrusive
Coding
Structure
Description
SYNC Non-intrusive
n/a
1
1
The SYNC command is a special operation that does not have a command code.
Request a timed reference pulse to determine
target BDC communication speed
ACK_ENABLE Non-intrusive D5/d
Enable acknowledge protocol. Refer to
Freescale document order no. HCS08RMv1/D.
ACK_DISABLE Non-intrusive D6/d
Disable acknowledge protocol. Refer to
Freescale document order no. HCS08RMv1/D.
BACKGROUND Non-intrusive 90/d
Enter active background mode if enabled
(ignore if ENBDM bit equals 0)
READ_STATUS Non-intrusive E4/SS Read BDC status from BDCSCR
WRITE_CONTROL Non-intrusive C4/CC Write BDC controls in BDCSCR
READ_BYTE Non-intrusive E0/AAAA/d/RD Read a byte from target memory
READ_BYTE_WS Non-intrusive E1/AAAA/d/SS/RD Read a byte and report status
READ_LAST Non-intrusive E8/SS/RD
Re-read byte from address just read and
report status
WRITE_BYTE Non-intrusive C0/AAAA/WD/d Write a byte to target memory
WRITE_BYTE_WS Non-intrusive C1/AAAA/WD/d/SS Write a byte and report status
READ_BKPT Non-intrusive E2/RBKP Read BDCBKPT breakpoint register
WRITE_BKPT Non-intrusive C2/WBKP Write BDCBKPT breakpoint register
GO Active BDM 08/d
Go to execute the user application program
starting at the address currently in the PC
TRACE1 Active BDM 10/d
Trace 1 user instruction at the address in the
PC, then return to active background mode
TAGGO Active BDM 18/d
Same as GO but enable external tagging
(HCS08 devices have no external tagging pin)
READ_A Active BDM 68/d/RD Read accumulator (A)
READ_CCR Active BDM 69/d/RD Read condition code register (CCR)
READ_PC Active BDM 6B/d/RD16 Read program counter (PC)
READ_HX Active BDM 6C/d/RD16 Read H and X register pair (H:X)
READ_SP Active BDM 6F/d/RD16 Read stack pointer (SP)
READ_NEXT Active BDM 70/d/RD
Increment H:X by one then read memory byte
located at H:X
READ_NEXT_WS Active BDM 71/d/SS/RD
Increment H:X by one then read memory byte
located at H:X. Report status and data.
WRITE_A Active BDM 48/WD/d Write accumulator (A)
WRITE_CCR Active BDM 49/WD/d Write condition code register (CCR)
WRITE_PC Active BDM 4B/WD16/d Write program counter (PC)
WRITE_HX Active BDM 4C/WD16/d Write H and X register pair (H:X)
WRITE_SP Active BDM 4F/WD16/d Write stack pointer (SP)
WRITE_NEXT Active BDM 50/WD/d
Increment H:X by one, then write memory byte
located at H:X
WRITE_NEXT_WS Active BDM 51/WD/d/SS
Increment H:X by one, then write memory byte
located at H:X. Also report status.
