Chapter 18 Debug Module (DBG) (128K)
MC9S08QE128 MCU Series Reference Manual, Rev. 2
324 Freescale Semiconductor
18.3.2
Table 18-2. Register Bit Summary
76543210
DBGCAH Bit 15 Bit 14 Bit 13 Bit 12 Bit 11 Bit 10 Bit 9 Bit 8
DBGCAL Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
DBGCBH Bit 15 Bit 14 Bit 13 Bit 12 Bit 11 Bit 10 Bit 9 Bit 8
DBGCBL Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
DBGCCH Bit 15 Bit 14 Bit 13 Bit 12 Bit 11 Bit 10 Bit 9 Bit 8
DBGCCL Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
DBGFH Bit 15 Bit 14 Bit 13 Bit 12 Bit 11 Bit 10 Bit 9 Bit 8
DBGFL Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
DBGCAX RWAEN RWA PAGSEL 0000bit-16
DBGCBX RWBEN RWB PAGSEL 0000bit-16
DBGCCX RWCEN RWC PAGSEL 0000bit-16
DBGFX PPACC000000bit-16
DBGC DBGEN ARM TAG BRKEN - - - LOOP1
DBGT TRGSEL BEGIN 0 0 TRG[3:0]
DBGS AFBFCF0000ARMF
DBGCNT 0000 CNT[3:0]
