Chapter 4 Memory
MC9S08QE128 MCU Series Reference Manual, Rev. 2
60 Freescale Semiconductor
0x181F DBGCNT
0 0 0 0 CNT
0x1820 FCDIV FDIVLD PRDIV8 FDIV
0x1821 FOPT KEYEN
0 0 0 0 SEC
0x1822 Reserved
— — — — — — — —
0x1823 FCNFG
0 0 KEYACC 0 0 0 0 0
0x1824 FPROT FPS FPOPEN
0x1825 FSTAT FCBEF FCCF FPVIOL FACCERR
0 FBLANK 0 0
0x1826 FCMD
0 FCMD
0x1827-
0x1829
Reserved
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
0x182A Reserved
0x182B-
0x182F
Reserved
— — — — — — — —
0x1830 RTCSC RTIF RTCLKS RTIE RTCPS
0x1831 RTCCNT RTCCNT
0x1832 RTCMOD RTCMOD
0x1833-
0x1837
Reserved
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
0x1838 SPI2C1 SPIE SPE SPTIE MSTR CPOL CPHA SSOE LSBFE
0x1839 SPI2C2
0 0 0 MODFEN BIDIROE 0 SPISWAI SPC0
0x183A SPI2BR
0 SPPR2 SPPR1 SPPR0 0 SPR2 SPR1 SPR0
0x183B SPI2S SPRF
0 SPTEF MODF 0 0 0 0
0x183C Reserved
0 0 0 0 0 0 0 0
0x183D SPI2D Bit 7 654321Bit 0
0x183E-
0x183F
Reserved
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
0x1840 PTAPE PTAPE7 PTAPE6 PTAPE5 PTAPE4 PTAPE3 PTAPE2 PTAPE1 PTAPE0
0x1841 PTASE PTASE7 PTASE6 PTASE5 PTASE4 PTASE3 PTASE2 PTASE1 PTASE0
0x1842 PTADS PTADS7 PTADS6 PTADS5 PTADS4 PTADS3 PTADS2 PTADS1 PTADS0
0x1843 Reserved
— — — — — — — —
0x1844 PTBPE PTBPE7 PTBPE6 PTBPE5 PTBPE4 PTBPE3 PTBPE2 PTBPE1 PTBPE0
0x1845 PTBSE PTBSE7 PTBSE6 PTBSE5 PTBSE4 PTBSE3 PTBSE2 PTBSE1 PTBSE0
0x1846 PTBDS PTBDS7 PTBDS6 PTBDS5 PTBDS4 PTBDS3 PTBDS2 PTBDS1 PTBDS0
0x1847 Reserved
— — — — — — — —
0x1848 PTCPE PTCPE7 PTCPE6 PTCPE5 PTCPE4 PTCPE3 PTCPE2 PTCPE1 PTCPE0
0x1849 PTCSE PTCSE7 PTCSE6 PTCSE5 PTCSE4 PTCSE3 PTCSE2 PTCSE1 PTCSE0
0x184A PTCDS PTCDS7 PTCDS6 PTCDS5 PTCDS4 PTCDS3 PTCDS2 PTCDS1 PTCDS0
0x184B Reserved
— — — — — — — —
0x184C PTDPE PTDPE7 PTDPE6 PTDPE5 PTDPE4 PTDPE3 PTDPE2 PTDPE1 PTDPE0
0x184D PTDSE PTDSE7 PTDSE6 PTDSE5 PTDSE4 PTDSE3 PTDSE2 PTDSE1 PTDSE0
0x184E PTDDS PTDDS7 PTDDS6 PTDDS5 PTDDS4 PTDDS3 PTDDS2 PTDDS1 PTDDS0
0x184F Reserved
— — — — — — — —
0x1850 PTEPE PTEPE7 PTEPE6 PTEPE5 PTEPE4 PTEPE3 PTEPE2 PTEPE1 PTEPE0
Table 4-3. High-Page Register Summary (Sheet 2 of 4)
Address Register Name Bit 7 654321Bit 0
