19
Before You Play
Once you’ve got everything connected properly, you
can turn on the power using the following procedure.
If you fail to perform these steps in the correct order,
you risk causing a malfunction or damaging the
speakers.
Turning the Power On
1.
Turn the [Volume] knob all the way toward the
left to minimize the volume.
fig.VolumeMin.eps
2.
Press the [Power] switch.
fig.PowerOn.eps
The power will turn on, and the [Piano] and other
buttons will light.
3.
Use the [Volume] knob to adjust the volume (p.
20).
The unit becomes operable and playing the keyboard
produces sound.
Due to a circuitry protection feature, this unit requires
a few moments after power is turned on before it is
ready for normal operation.
Turning the Power Off
1.
Turn the [Volume] knob all the way toward the
left to minimize the volume.
fig.VolumeMin.eps
2.
Press the [Power] switch.
The screen goes blank and the power is turned off.
ig.PowerOn.eps
Turning the Power On/Off
NOTE
Power
On
Lower
Position
NOTE
Power
Off
Upper Position
FP-7-e.book 19 ページ 2006年12月14日 木曜日 午前10時57分

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Roland FP-7 and is the answer not in the manual?

Roland FP-7 Specifications

General IconGeneral
Amplifier13 W x 2
Keyboard88 keys (PHA II keyboard with Escapement)
Touch Sensitivity5 types, fixed touch
Sound Generator128-note polyphony
EffectsReverb, Chorus
Speakers12 cm x 2
ConnectivityMIDI (In, Out), USB, Headphones, Line Out, Pedal
Recorder3-track recorder
Display128 x 64 dots
Included AccessoriesOwner's Manual, Music Rest
Internal MemoryExternal storage: USB memory
