The JUPITER-80’s System Settings
86
Output Assign
Here you can specify which sounds will be sent from each output
jack. Select the desired check boxes for each output jack (MAIN
OUT, SUB OUT).
Parameter Explanation
Upper Upper Part
Lower Lower Part
Solo Solo Part
Percussion Percussion Part
Reverb Upper The reverb of the Upper Part
Reverb Lower The reverb of the Lower Part
Reverb Solo/Perc The reverb of the Solo and Percussion Parts
USB Song/Audio
IN
The sound from the USB memory song player and the AUDIO
IN jack
USB Audio The sound from USB audio
Metronome The metronome sound
Sync/Metronome
Parameter Value Explanation
Sync
Sync Mode
This selects the synchronization source used by the
JUPITER-80.
MASTER
The JUPITER-80 will be the synchronization
master. Choose this setting if you’re using the
JUPITER-80 on its own without synchronizing
it to another device, or if you want the tempo
of an external MIDI device to synchronize
with the JUPITER-80.
SLAVE
The JUPITER-80 will be the synchronization
slave. Choose this setting if you want the
JUPITER-80 to synchronize to MIDI clock
messages received from an external device.
Sync Output OFF, ON
If this is ON, MIDI clock messages will be
transmitted to an external MIDI device.
* These messages will not be transmitted if
the Sync Mode is “SLAVE.”
Clock Source
This species whether the JUPITER-80 will synchronize to
tempo data from the MIDI IN connector or to tempo data
from the USB connector when the Sync Mode is SLAVE.
MIDI
Synchronize to tempo data from the MIDI IN
connector.
USB
Synchronize to tempo data from the USB
COMPUTER connector.
Metronome
Metronome Level 0–10 Species the metronome volume.
Metronome Sound TYPE1–TYPE4 Species the metronome type.
System Control
Parameter Value Explanation
System Control
1–4 Source
Here you can specify the MIDI messages that will be used as
system controls.
System controls 1–4 are parameters to which you can assign
MIDI messages such as control change messages.
For example, on the JUPITER-80, if you choose a system control
as the MFX CONTROL Source (Live Set MFX screen; p. 33), you’ll be
able to use MIDI messages to control eect parameters.
It is convenient to use system controls when you don’t need to
use dierent MIDI messages for MFX CONTROL of each Live Set,
or if you want to use a specic MIDI message for MFX CONTROL.
SuperNATURAL Acoustic Tones can be controlled using the
MIDI messages that you’ve assigned to system controls 1 and 2,
allowing you to produce eects such as vibrato or dynamics (for
some tones there will be no change).
OFF System control will not be used.
CC01–31, CC32
(OFF), 33–95
Controller 1–95
PITCH BEND Pitch Bend
AFTERTOUCH Aftertouch
Screen Saver
Parameter Value Explanation
Screen Saver
Type
1–10 Selects the type of screen saver.
Screen Saver
Time
OFF, 1–60 [min]
Species the time (minutes) until the
screen saver is activated.
If this is OFF, the screen saver will not
operate.
Beep/Misc
Parameter Value Explanation
Beep
Beep Switch OFF, ON
Turns on/o the beep tone that sounds
when you touch the screen.
Misc
Registration Next/
Prev Button
Species the operation of the Registration [PREV] and [NEXT]
buttons.
REGISTRATION
Switch to the next/previous Registration
number (p. 42).
REGISTRATION
SET
Switch to the next/previous Registration
Set (p. 42).
Visual Control
Mode
MVC
Choose if controlling a MIDI Visual
Control compatible device.
V-LINK
Choose if controlling a V-LINK compat-
ible device.
Startup
Parameter Value Explanation
Startup
Registration
[01]A-1 – [08]D-8
Species the Registration that will be
selected when you turn on the power.
