157
Effect/Parameter List
13: MULT PHASER
(MULTI STAGE PHASER)
Extremely high settings of the phase difference produce a
deep phaser effect.
14: INF PHASER (INFINITE PHASER)
A phaser that continues raising/lowering the frequency at
which the sound is modulated.
15: RING MODLTR (RING MODULATOR)
This is an effect that applies amplitude modulation (AM) to the
input signal, producing bell-like sounds. You can also change
the modulation frequency in response to changes in the
volume of the sound sent into the effect.
16: STEP R.MOD
(STEP RING MODULATOR)
This is a ring modulator that uses a 16-step sequence to vary
the frequency at which modulation is applied.
Polarity
INVERSE,
SYNCHRO
Selects whether the left and right
phase of the modulation will be the
same or the opposite.
INVERSE
: The left and right phase will
be opposite. When using a mono
source, this spreads the sound.
SYNCHRO
: The left and right phase
will be the same. Select this when
inputting a stereo source.
Resonance 0–127 Amount of feedback
Cross Feedback -98– +98%
Adjusts the proportion of the phaser
sound that is fed back into the effect.
Negative (-) settings will invert the
phase.
Step Rate Mode Hz, note
When this is set to “note,” the effect is
synchronized with the tempo.
StepRate(Hz) 0.10–20.00 Hz
Rate of the step-wise change in the
phaser effect (Hz)
Step Rate ( ) note (*1)
Rate of the step-wise change in the
phaser effect (note)
Mix 0–127 Level of the phase-shifted sound
Low Gain -15– +15 dB Gain of the low range
High Gain -15– +15 dB Gain of the high range
Level 0–127 Output Level
Assignable Parameters
MFX Control
Rate, Depth, Resonance, Manual, Mix
Parameter
Value Description
Mode
4-STAGE,
8-STAGE,
12-STAGE,
16-STAGE,
20-STAGE,
24-STAGE
Number of phaser stages
Manual 0–127
Adjusts the basic frequency from
which the sound will be modulated.
Rate Mode Hz, note
When this is set to “note,” the effect is
synchronized with the tempo.
Rate (Hz) 0.05–10.00 Hz Frequency of modulation (Hz)
Rate ( ) note (*1) Frequency of modulation (note)
Depth 0–127 Depth of modulation
Resonance 0–127 Amount of feedback
Mix 0–127 Level of the phase-shifted sound
Pan L64–63R Stereo location of the output sound
Low Gain -15– +15 dB Gain of the low range
High Gain -15– +15 dB Gain of the high range
Level 0–127 Output Level
Assignable Parameters
MFX Control Speed, Resonance, Mix, Pan
Parameter
Value Description
Mode
1, 2, 3, 4
Higher values will produce a deeper
phaser effect.
Parameter
Value Description
Speed -100– +100
Speed at which to raise or lower the
frequency at which the sound is
modulated
(+: upward / -: downward)
Resonance 0–127 Amount of feedback
Mix 0–127 Volume of the phase-shifted sound
Pan L64–63R Panning of the output sound
Low Gain -15– +15 dB
Amount of boost/cut for the low-
frequency range
High Gain -15– +15 dB
Amount of boost/cut for the high-
frequency range
Level 0–127 Output volume
Assignable Parameters
MFX Control Frequency, Sens, Balance
Parameter
Value Description
Frequency 0–127
Adjusts the frequency at which
modulation is applied.
Sens 0–127
Adjusts the amount of frequency
modulation applied.
Polarity UP, DOWN
Determines whether the frequency
modulation moves towards higher
frequencies (UP) or lower frequencies
(DOWN).
Low Gain -15– +15 dB Gain of the low frequency range
High Gain -15– +15 dB Gain of the high frequency range
Balance
D100:0W–
D0:100W
Volume balance between the direct
sound (D) and the effect sound (W)
Level 0–127 Output level
Assignable Parameters
MFX Control
Rate, Attack, Balance
Parameter
Value Description
Step 01–16
0–127
Frequency of ring modulation at each
step
Rate Mode Hz, note
When this is set to “note,” the effect is
synchronized with the tempo.
Rate (Hz) 0.05–10.00 Hz
Rate at which the 16-step sequence
will cycle (Hz)
Rate ( ) note (*1)
Rate at which the 16-step sequence
will cycle (note)
Attack 0–127
Speed at which the modulation
frequency changes between steps
Low Gain -15– +15 dB
Amount of boost/cut for the low-
frequency range
High Gain -15– +15 dB
Amount of boost/cut for the high-
frequency range
Balance
D100:0W–
D0:100W
Volume balance of the original sound
(D) and effect sound (W)
Level 0–127 Output volume
Parameter
Value Description
RD-700GX_e.book 157 ページ ２００８年２月１３日 水曜日 午後５時４９分
