158
Effect/Parameter List
17: TREMOLO
Cyclically modulates the volume to add tremolo effect to the sound.
18: AUTO PAN
Cyclically modulates the stereo location of the sound.
19: STEP PAN
This uses a 16-step sequence to vary the panning of the sound.
20: SLICER
By applying successive cuts to the sound, this effect turns a
conventional sound into a sound that appears to be played as
a backing phrase. This is especially effective when applied to
sustain-type sounds.
21: ROTARY
The Rotary effect simulates the sound of the rotary speakers
often used with the electric organs of the past. Since the
movement of the high range and low range rotors can be set
independently, the unique type of modulation characteristic of
these speakers can be simulated quite closely. This effect is
most suitable for electric organ Patches.
Assignable Parameters
MFX Control
Rate, Depth, Mod Wave
Parameter Value Description
Mod Wave
TRI, SQR, SIN,
SAW1, SAW2
Modulation Wave
TRI
: Triangle wave
SQR
: Square wave
SIN
: Sine wave
SAW1/2
: Sawtooth wave
Rate Mode Hz, note
When this is set to “note,” the effect is
synchronized with the tempo.
Rate (Hz) 0.05–10.00 Hz Frequency of the change (Hz)
Rate ( ) note (*1) Frequency of the change (note)
Depth 0–127 Depth to which the effect is applied
Low Gain -15– +15 dB Gain of the low range
High Gain -15– +15 dB Gain of the high range
Level 0–127 Output Level
Assignable Parameters
MFX Control
Rate, Depth, Mod Wave
Parameter
Value Description
Mod Wave
TRI, SQR, SIN,
SAW1, SAW2
Modulation Wave
TRI
: triangle wave
SQR
: square wave
SIN
: sine wave
SAW1/2
: sawtooth wave
Rate Mode Hz, note
When this is set to “note,” the effect is
synchronized with the tempo.
Rate (Hz) 0.05–10.00 Hz Frequency of the change (Hz)
Rate ( ) note (*1) Frequency of the change (note)
Depth 0–127 Depth to which the effect is applied
Low Gain -15– +15 dB Gain of the low range
High Gain -15– +15 dB Gain of the high range
Level 0–127 Output Level
Assignable Parameters
MFX Control
Rate, Attack
Parameter
Value Description
Step 01–16
L64–63R Pan at each step
Rate Mode Hz, note
When this is set to “note,” the effect is
synchronized with the tempo.
1
SAW1 SAW2
L
R
L
R
Rate (Hz)
0.05–10.00 Hz
Rate at which the 16-step sequence
will cycle (Hz)
Rate ( ) note (*1)
Rate at which the 16-step sequence
will cycle (note)
Attack 0–127
Speed at which the pan changes
between steps
Input Sync Sw OFF, ON
Specifies whether an input note will
cause the sequence to resume from the
first step of the sequence (ON) or not
(OFF)
Input Sync Thres 0–127
Volume at which an input note will be
detected
Level 0–127 Output volume
Assignable Parameters
MFX Control
Rate, Attack, Shuffle
Parameter
Value Description
Step 01–16
0–127 Level at each step
Rate Mode Hz, note
When this is set to “note,” the effect is
synchronized with the tempo.
Rate (Hz) 0.05–10.00 Hz
Rate at which the 16-step sequence
will cycle (Hz)
Rate ( ) note (*1)
Rate at which the 16-step sequence
will cycle (note)
Attack 0–127
Speed at which the level changes
between steps
Input Sync Sw OFF, ON
Specifies whether an input note will
cause the sequence to resume from the
first step of the sequence (ON) or not
(OFF)
Input Sync Thres 0–127
Volume at which an input note will be
detected
Mode
LEGATO,
SLASH
Sets the manner in which the volume
changes as one step progresses to the
next.
LEGATO
: The change in volume from
one step’s level to the next remains
unaltered. If the level of a following
step is the same as the one preceding
it, there is no change in volume.
SLASH
: The level is momentarily set to
0 before progressing to the level of the
next step. This change in volume
occurs even if the level of the following
step is the same as the preceding step.
Shuffle 0–127
Timing of volume changes for even-
numbered steps (step 2, step 4, step
6...).
The higher the value, the later the beat
progresses.
Level 0–127 Output level
Assignable Parameters
MFX Control Speed, Tw Fast Rate, Wf Fast Rate, Separation
Parameter
Value Description
RD-700GX_e.book 158 ページ ２００８年２月１３日 水曜日 午後５時４９分
