168
Effect/Parameter List
54: LONG TC DLY
(LONG TIME CTRL DELAY)
A delay in which the delay time can be varied smoothly, and
allowing an extended delay to be produced.
55: TAPE ECHO
A virtual tape echo that produces a realistic tape delay sound.
This simulates the tape echo section of a Roland RE-201 Space
Echo.
56: LOFI NOISE
In addition to a lo-fi effect, this adds various types of noise
such as white noise and disc noise.
HF Damp
200–8000 Hz,
BYPASS
Adjusts the frequency above which
sound fed back to the effect is filtered
out. If you do not want to filter out any
high frequencies, set this parameter to
BYPASS.
Low Gain -15– +15 dB Gain of the low frequency range
High Gain -15– +15 dB Gain of the high frequency range
Balance
D100:0W–
D0:100W
Volume balance between the direct
sound (D) and the delay sound (W)
Level 0–127 Output level
Assignable Parameters
MFX Control
Balance, Delay
Parameter
Value Description
Delay Mode
ms, note
When this is set to “note,” the effect is
synchronized with the tempo.
Delay (ms) 1–2600 ms
Adjusts the time until the delay is
heard. (Hz)
Delay ( ) note (*1)
Adjusts the time until the delay is
heard. (note)
Acceleration 0–15
Adjusts the time over which the Delay
Time changes from the current setting
to a specified new setting.
The rate of change for the Delay Time
directly affects the rate of pitch
change.
Feedback -98– +98%
Adjusts the amount of the delay that’s
fed back into the effect. Negative (-)
settings invert the phase.
HF Damp
200–8000 Hz,
BYPASS
Adjusts the frequency above which
sound fed back to the effect is filtered
out. If you do not want to filter out any
high frequencies, set this parameter to
BYPASS.
Pan L64–63R Stereo location of the delay
Low Gain -15– +15 dB Gain of the low frequency range
High Gain -15– +15 dB Gain of the high frequency range
Balance
D100:0W–
D0:100W
Volume balance between the direct
sound (D) and the delay sound (W)
Level 0–127 Output level
Assignable Parameters
MFX Control
Echo Level, Repeat Rate, Mode
Parameter
Value Description
Mode
S, M, L, S+M,
S+L, M+L,
S+M+L
Combination of playback heads to use
Select from three different heads with
different delay times.
S
: short
M
: middle
L
: long
Repeat Rate 0–127
Tape speed
Increasing this value will shorten the
spacing of the delayed sounds.
Intensity 0–127 Amount of delay repeats
Bass -15– +15 dB
Boost/cut for the lower range of the
echo sound
Treble -15– +15 dB
Boost/cut for the upper range of the
echo sound
Parameter
Value Description
Head S Pan
L64–63R
Independent panning for the short,
middle, and long playback heads
Head M Pan
Head L Pan
Tape Distortion 0–5
Amount of tape-dependent distortion
to be added
This simulates the slight tonal changes
that can be detected by signal-
analysis equipment. Increasing this
value will increase the distortion.
W/F Rate 0–127
Speed of wow/flutter (complex
variation in pitch caused by tape wear
and rotational irregularity)
W/F Depth 0–127 Depth of wow/flutter
Echo Level 0–127 Volume of the echo sound
Direct Level 0–127 Volume of the original sound
Level 0–127 Output level
Assignable Parameters
MFX Control
Balance, Hum Noise Level, Disc Noise Level, Noise Level,
LoFi Type
Parameter
Value Description
LoFi Type
1–9
Degrades the sound quality. The
sound quality grows poorer as this
value is increased.
Post Fltr Type OFF, LPF, HPF
Type of filter
OFF
: no filter is used
LPF
: cuts the frequency range above
the Cutoff
HPF
: cuts the frequency range below
the Cutoff
Post F-Cutoff 200–8000 Hz Center frequency of the filter
Noise Type WHITE, PINK
Switch between white noise and pink
noise.
Noise LPF
200–8000 Hz,
BYPASS
Center frequency of the low pass filter
applied to the white/pink noise
(BYPASS: no cut)
Noise Level 0–127 Volume of the white/pink noise
Disc Noise Type LP, EP, SP, RND
Type of record noise
The frequency at which the noise is
heard depends on the selected type.
DiscNoise LPF
200–8000 Hz,
BYPASS
Adjusts the cutoff frequency of the low
pass filter applied to the record noise.
If you don’t want to filter out any high
frequencies, set this parameter to
BYPASS.
Disc Noise Level 0–127 Volume of the record noise
Hum Noise
Type
50 Hz, 60 Hz Frequency of the hum noise
Hum Noise LPF
200–8000 Hz,
BYPASS
Center frequency of the low pass filter
applied to the hum noise (BYPASS: no
cut)
Hum Noise
Level
0–127 Volume of the hum noise
Low Gain -15– +15 dB Gain of the low range
High Gain -15– +15 dB Gain of the high range
Balance
D100:0W–
D0:100W
Volume balance between the direct
sound (D) and the effect sound (W)
Level 0–127 Output level
Parameter
Value Description
