167
Effect/Parameter List
51: SHUFFLE DLY (SHUFFLE DELAY)
Adds a shuffle to the delay sound, giving the sound a bouncy
delay effect with a swing feel.
52: 3D DELAY
This applies a 3D effect to the delay sound. The delay sound
will be positioned 90 degrees left and 90 degrees right.
53: T-CTRL DLY(TIME CTRL DELAY)
A stereo delay in which the delay time can be varied smoothly.
Delay2 Mode
ms, note
Settings of the Delay 2
The parameters are the same as for
the Delay 1.
Delay2 (ms) 1–1300 ms
Delay2 ( ) note (*1)
Delay3 Mode ms, note
Settings of the Delay 3
The parameters are the same as for
the Delay 1.
Delay3 (ms) 1–1300 ms
Delay3 ( ) note (*1)
Delay3
Feedback
-98– +98%
Proportion of the delay sound that is to
be returned to the input of the tap
delay (negative values invert the
phase)
Delay HF Damp
200–8000 Hz,
BYPASS
Frequency at which the low-frequency
content of the tap delay sound will be
cut (BYPASS: no cut)
Delay1 Pan
L64–63R Panning of the tap delay sounds
Delay2 Pan
Delay1 Level
0–127 Volume of the tap delay sounds
Delay2 Level
Low Gain -15– +15 dB
Amount of boost/cut for the low-
frequency range
High Gain -15– +15 dB
Amount of boost/cut for the high-
frequency range
Balance
D100:0W–
D0:100W
Volume balance of the original sound
(D) and delay sound (W)
Level 0–127 Output volume
Assignable Parameters
MFX Control
Balance, Delay, Shuffle Rate
Parameter
Value Description
Delay Mode
ms, note
When this is set to “note,” the effect is
synchronized with the tempo.
Delay (ms) 1–2600 ms
Adjusts the time until the delay sound
is heard. (Hz)
Delay ( ) note (*1)
Adjusts the time until the delay sound
is heard. (note)
Shuffle Rate 0–100%
Adjusts the ratio (as a percentage) of
the time that elapses before Delay B
sounds relative to the time that elapses
before the Delay A sounds.
When set to 100%, the delay times
are the same.
Acceleration 0–15
Adjusts the time over which the Delay
Time changes from the current setting
to its specified new setting.
Feedback -98– +98%
Adjusts the amount of the delay that’s
fed back into the effect. Negative (-)
settings invert the phase.
HF Damp
200–8000 Hz,
BYPASS
Adjusts the frequency above which
sound fed back to the effect is filtered
out. If you don’t want to filter out any
high frequencies, set this parameter to
BYPASS.
Pan A
L64–63R Stereo location of Delay A/B
Pan B
Level A
0–127 Volume of delay A/B
Level B
Low Gain -15– +15 dB Gain of the low frequency range
High Gain -15– +15 dB Gain of the high frequency range
Balance
D100:0W–
D0:100W
Volume balance between the direct
sound (D) and the effect sound (W)
Level 0–127 Output level
Parameter
Value Description
Assignable Parameters
MFX Control
Balance, Delay C, Delay L, Delay R
Parameter
Value Description
Delay L Mode ms, note
When this is set to “note,” the effect is
synchronized with the tempo.
Delay L (ms) 1–2600 ms
Adjusts the delay time from the direct
sound until the delay sound is heard.
(Hz)
Delay L ( ) note (*1)
Adjusts the delay time from the direct
sound until the delay sound is heard.
(note)
Delay R Mode ms, note
Settings of the Delay R
The parameters are the same as for
the Delay 1.
Delay R (ms) 1–2600 ms
Delay R ( ) note (*1)
Delay C Mode ms, note
Settings of the Delay C
The parameters are the same as for
the Delay 1.
Delay C (ms) 1–2600 ms
Delay C ( ) note (*1)
Center
Feedback
-98– +98%
Adjusts the proportion of the delay
sound that is fed back into the effect.
Negative (-) settings will invert the
phase.
HF Damp
200–8000 Hz,
BYPASS
Adjusts the frequency above which
sound fed back to the effect will be
cut. If you do not want to cut the high
frequencies, set this parameter to
BYPASS.
Left Level
0–127 Output level of the delay soundRight Level
Center Level
Output Mode
SPEAKER,
PHONES
Adjusts the method that will be used to
hear the sound that is output to the
OUTPUT jacks. The optimal 3D effect
will be achieved if you select SPEAKER
when using speakers, or PHONES
when using headphones.
Low Gain -15– +15 dB Gain of the low range
High Gain -15– +15 dB Gain of the high range
Balance
D100:0W–
D0:100W
Volume balance between the direct
sound (D) and the effect sound (W)
Level 0–127 Output Level
Assignable Parameters
MFX Control
Balance, Delay
Parameter Value Description
Delay Mode
ms, note
When this is set to “note,” the effect is
synchronized with the tempo.
Delay (ms) 1–1300 ms
Adjusts the time until the delay is
heard. (Hz)
Delay ( ) note (*1)
Adjusts the time until the delay is
heard. (note)
Acceleration 0–15
Adjusts the time over which the Delay
Time changes from the current setting
to a specified new setting.
The rate of change for the Delay Time
directly affects the rate of pitch
change.
Feedback -98– +98%
Adjusts the amount of the delay that’s
fed back into the effect. Negative (-)
settings invert the phase.
RD-700GX_e.book 167 ページ ２００８年２月１３日 水曜日 午後５時４９分
