166
Effect/Parameter List
48: 4TP PAN DLY (4TAP PAN DELAY)
This effect has four delays.
Stereo location of each delay
49: MULTTAP DLY (MULTI TAP DELAY)
This effect provides four delays. Each of the Delay Time
parameters can be set to a note length based on the selected
tempo. You can also set the panning and level of each delay
sound.
50: REVERSE DLY (REVERSE DELAY)
This is a reverse delay that adds a reversed and delayed
sound to the input sound. A tap delay is connected
immediately after the reverse delay.
Assignable Parameters
MFX Control Balance, Delay1, Delay2, Delay3, Delay4
Parameter Value Description
Delay1 Mode
ms, note
When this is set to “note,” the effect is
synchronized with the tempo.
Delay1 (ms) 1–2600 ms
Adjusts the time until the delay sound
is heard. (Hz)
Delay1 ( ) note (*1)
Adjusts the time until the delay sound
is heard. (note)
Delay2 Mode ms, note
Settings of the Delay 2
The parameters are the same as for
the Delay 1.
Delay2 (ms) 1–2600 ms
Delay2 ( ) note (*1)
Delay3 Mode ms, note
Settings of the Delay 3
The parameters are the same as for
the Delay 1.
Delay3 (ms) 1–2600 ms
Delay3 ( ) note (*1)
Delay4 Mode ms, note
Settings of the Delay 4
The parameters are the same as for
the Delay 1.
Delay4 (ms) 1–2600 ms
Delay4 ( ) note (*1)
Delay1
Feedback
-98– +98%
Adjusts the amount of the delay sound
that’s fed back into the effect.
Negative
(-) settings invert the phase.
HF Damp
200–8000 Hz,
BYPASS
Adjusts the frequency above which
sound fed back to the effect is filtered
out. If you do not want to filter out any
high frequencies, set this parameter to
BYPASS.
Delay1 Level
0–127 Volume of each delay
Delay2 Level
Delay3 Level
Delay4 Level
Low Gain -15– +15 dB Gain of the low frequency range
High Gain -15– +15 dB Gain of the high frequency range
Balance
D100:0W–
D0:100W
Volume balance between the direct
sound (D) and the delay sound (W)
Level 0–127 Output level
Assignable Parameters
MFX Control
Balance, Delay1, Delay2, Delay3, Delay4
Parameter
Value Description
Delay1 Mode
ms, note
When this is set to “note,” the effect is
synchronized with the tempo.
Delay1 (ms) 1–2600 ms
Adjusts the time until the delay sound
is heard. (Hz)
Delay1 ( ) note (*1)
Adjusts the time until the delay sound
is heard. (note)
1
23
4
L
R
Delay2 Mode
ms, note
Settings of the Delay 2
The parameters are the same as for
the Delay 1.
Delay2 (ms) 1–2600 ms
Delay2 ( ) note (*1)
Delay3 Mode ms, note
Settings of the Delay 3
The parameters are the same as for
the Delay 1.
Delay3 (ms) 1–2600 ms
Delay3 ( ) note (*1)
Delay4 Mode ms, note
Settings of the Delay 4
The parameters are the same as for
the Delay 1.
Delay4 (ms) 1–2600 ms
Delay4 ( ) note (*1)
Delay1
Feedback
-98– +98%
Adjusts the amount of the delay sound
that’s fed back into the effect.
Negative (-) settings invert the phase.
HF Damp
200–8000 Hz,
BYPASS
Adjusts the frequency above which
sound fed back to the effect is filtered
out. If you don’t want to filter out any
the high frequencies, set this
parameter to BYPASS.
Delay1 Pan L64–63R Stereo location of Delays 1
Delay2 Pan L64–63R Stereo location of Delays 2
Delay3 Pan L64–63R Stereo location of Delays 3
Delay4 Pan L64–63R Stereo location of Delays 4
Delay1 Level 0–127 Output level of Delays 1
Delay2 Level 0–127 Output level of Delays 2
Delay3 Level 0–127 Output level of Delays 3
Delay4 Level 0–127 Output level of Delays 4
Low Gain -15– +15 dB Gain of the low frequency range
High Gain -15– +15 dB Gain of the high frequency range
Balance
D100:0W–
D0:100W
Volume balance between the direct
sound (D) and the effect sound (W)
Level 0–127 Output level
Assignable Parameters
MFX Control Balance, Rev Dly, Rev Dly Pan
Parameter
Value Description
Threshold
0–127
Volume at which the reverse delay will
begin to be applied
Rev Dly Mode ms, note
When this is set to “note,” the effect is
synchronized with the tempo.
Rev Dly (ms) 1–1300 ms
Delay time from when sound is input
into the reverse delay until the delay
sound is heard (Hz)
Rev Dly ( ) note (*1)
Delay time from when sound is input
into the reverse delay until the delay
sound is heard (note)
Rev Dly Fbk -98– +98%
Proportion of the delay sound that is to
be returned to the input of the reverse
delay (negative values invert the
phase)
Rev Dly HFDmp
200–8000 Hz,
BYPASS
Frequency at which the high-frequency
content of the reverse-delayed sound
will be cut (BYPASS: no cut)
Rev Dly Pan L64–63R Panning of the reverse delay sound
Rev Dly Level 0–127 Volume of the reverse delay sound
Delay1 Mode ms, note
When this is set to “note,” the effect is
synchronized with the tempo.
Delay1 (ms) 1–1300 ms
Delay time from when sound is input
into the tap delay until the delay sound
is heard (Hz)
Delay1 ( ) note (*1)
Delay time from when sound is input
into the tap delay until the delay sound
is heard (note)
Parameter
Value Description
RD-700GX_e.book 166 ページ ２００８年２月１３日 水曜日 午後５時４９分
