Roland RD-700GX User Manual

171
Effect/Parameter List
66: OVDRV → CHO
(OVERDRIVE → CHORUS)
This effect connects an overdrive and a chorus in series.
67: OVDRV → FLNGR
(OVERDRIVE → FLANGER)
This effect connects an overdrive and a flanger in series.
68: OVDRV → DELAY
(OVERDRIVE → DELAY)
This effect connects an overdrive and a delay in series.
69: DIST → CHORUS
(DISTORTION → CHORUS)
The parameters are essentially the same as in “66:
OVERDRIVE → CHORUS,” with the exception of the following
two.
Overdrive Drive → Distortion Drive
Overdrive Pan → Distortion Pan
70: DIST → FLANGR
(DISTORTION → FLANGER)
The parameters are essentially the same as in “67:
OVERDRIVE → FLANGER,” with the exception of the following
two.
Overdrive Drive → Distortion Drive
Overdrive Pan → Distortion Pan
71: DIST → DELAY (DISTORTION → DELAY)
The parameters are essentially the same as in “68:
OVERDRIVE → DELAY,” with the exception of the following two.
Overdrive Drive → Distortion Drive
Overdrive Pan → Distortion Pan
Gate Time
5–500 ms
Adjusts the time from when the reverb
is heard until it disappears.
Low Gain -15– +15 dB Gain of the low range
High Gain -15– +15 dB Gain of the high range
Balance
D100:0W–
D0:100W
Volume balance between the direct
sound (D) and the reverb sound (W)
Level 0–127 Output Level
Assignable Parameters
MFX Control
Chorus Bal, Cho Rate, Chorus Depth, Overdrive Drive
Parameter
Value Description
Overdrive Drive
0–127
Degree of distortion
Also changes the volume.
Overdrive Pan L64–63R Stereo location of the overdrive sound
Chorus PreDly 0.0–100.0 ms
Adjusts the delay time from the direct
sound until the chorus sound is heard.
Rate Mode Hz, note
When this is set to “note,” the effect is
synchronized with the tempo.
Cho Rate(Hz) 0.05–10.00 Hz Frequency of modulation (Hz)
Cho Rate ( ) note (*1) Frequency of modulation (note)
Chorus Depth 0–127 Depth of modulation
Chorus Bal
D100:0W–
D0:100W
Adjusts the volume balance between
the sound that is sent through the
chorus (W) and the sound that is not
sent through the chorus (D).
Level 0–127 Output Level
Assignable Parameters
MFX Control
Flngr Bal, Fln Rate, Flngr Depth, Flngr Feedback,
Overdrive Drive
Parameter
Value Description
Overdrive Drive 0–127
Degree of distortion
Also changes the volume.
Overdrive Pan L64–63R Stereo location of the overdrive sound
Flngr PreDly 0.0–100.0 ms
Adjusts the delay time from when the
direct sound begins until the flanger
sound is heard.
Flngr Mode Hz, note
When this is set to “note,” the effect is
synchronized with the tempo.
Fln Rate(Hz) 0.05–10.00 Hz Frequency of modulation (Hz)
Fln Rate( ) note (*1) Frequency of modulation (note)
Flngr Depth 0–127 Depth of modulation
Flngr Feedback -98– +98%
Adjusts the proportion of the flanger
sound that is fed back into the effect.
Negative (-) settings will invert the
phase.
Flngr Bal
D100:0W–
D0:100W
Adjusts the volume balance between
the sound that is sent through the
flanger (W) and the sound that is not
sent through the flanger (D).
Level 0–127 Output Level
Parameter
Value Description
Assignable Parameters
MFX Control
Delay Bal, Overdrive Drive
Parameter Value Description
Overdrive Drive
0–127
Degree of distortion
Also changes the volume.
Overdrive Pan L64–63R Stereo location of the overdrive sound
Delay Mode ms, note
When this is set to “note,” the effect is
synchronized with the tempo.
Delay (ms) 1–2600 ms
Adjusts the delay time from the direct
sound until the delay sound is heard.
(Hz)
Delay ( ) note (*1)
Adjusts the delay time from the direct
sound until the delay sound is heard.
(note)
Delay Feedback -98– +98%
Adjusts the proportion of the delay
sound that is fed back into the effect.
Negative (-) settings will invert the
phase.
Delay HF Damp
200–8000 Hz,
BYPASS
Adjusts the frequency above which
sound fed back to the effect will be
cut. If you do not want to cut the high
frequencies, set this parameter to
BYPASS.
Delay Bal
D100:0W–
D0:100W
Adjusts the volume balance between
the sound that is sent through the delay
(W) and the sound that is not sent
through the delay (D).
Level 0–127 Output Level
RD-700GX_e.book 171 ページ ２００８年２月１３日 水曜日 午後５時４９分
