Roland RD-700GX User Manual

184
Effect/Parameter List
118:*ENH → DELAY
(ENHANCER → DELAY)
This effect connects an enhancer and a delay in series.
119: *CHO → DELAY (CHORUS → DELAY)
This effect connects a chorus and a delay unit in series.
120:*FLANGR → DLY (FLANGER → DELAY)
This effect connects a flanger and a delay in series.
121: *CHO → FLANGR
(CHORUS → FLANGER)
This effect connects a chorus and a flanger in series.
Assignable Parameters
MFX Control
Delay Bal, Enhancer Sens
Parameter
Value Description
Enhancer Sens 0–127 Adjust the sensitivity of the enhancer.
Enhancer Mix 0–127
Adjust the ratio with which the
overtones generated by the enhancer
are combined with the direct sound.
Delay Time 0.1–500.0 ms
Adjust the time delay from when the
direct sound begins until the delay
sound is heard.
Delay Feedback -98– +98%
Adjust the proportion (%) of the delay
sound that is fed back into the delay
input. Negative (-) settings will invert
the phase.
Delay HF Damp
200–8000 Hz,
BYPASS
Adjust the frequency above which
delayed sound fed back to the delay
input will be cut. If you do not want to
cut the high frequencies of the delay
feedback, set this parameter to
BYPASS.
Delay Bal
D100:0W–
D0:100W
Adjust the volume balance between
the enhancer sound that is sent
through the delay and the enhancer
sound that is not sent through the
delay. With a setting of “D100:0W,”
only the enhancer sound will be
output. With a setting of “D0:100W,”
only the enhancer sound that is sent
through the delay will be output.
Level 0–127 Adjust the output level.
Assignable Parameters
MFX Control Chorus Bal, Delay Bal
Parameter
Value Description
Chorus PreDly
0.0–100.0 ms
Adjust the time delay from when the
direct sound begins until the chorus
sound is heard.
Chorus Rate 0.05–10.00 Hz
Adjust the modulation speed of the
chorus effect.
Chorus Depth 0–127
Adjust the modulation depth of the
chorus effect.
Chorus Bal
D100:0W–
D0:100W
Adjust the volume balance between
the direct sound and the chorus sound.
With a setting of “D100:0W,” only
the direct sound will be output. With a
setting of “D0:100W,” only the
chorus sound will be output.
Delay Time 0.1–500.0 ms
Adjust the time delay from when the
direct sound begins until the delay
sound is heard.
Delay Feedback -98– +98%
Adjust the proportion (%) of the delay
sound that is fed back into the delay
input. Negative (-) settings will invert
the phase.
Delay HF Damp
200–8000 Hz,
BYPASS
Adjust the frequency above which
delayed sound fed back to the delay
input will be cut. If you do not want to
cut the high frequencies of the
feedback, set this parameter to
BYPASS.
Delay Bal
D100:0W–
D0:100W
Adjust the volume balance between
the chorus sound that is sent through
the delay and the chorus sound that is
not sent through the delay. With a
setting of “D100:0W,” only the
chorus sound will be output. With a
setting of “D0:100W,” only the
chorus sound that is sent through the
delay will be output.
Level 0–127 Adjust the output level.
Assignable Parameters
MFX Control
Flngr Bal, Delay Bal
Parameter
Value Description
Flngr PreDly
0.0–100.0 ms
Adjust the time delay from when the
direct sound begins until the flanger
sound is heard.
Flngr Rate 0.05–10.00 Hz
Adjust the modulation speed of the
flanger effect.
Flngr Depth 0–127
Adjust the modulation depth of the
flanger effect.
Flngr Fbk -98– +98%
Adjust the proportion (%) of the
flanger sound that is fed back into the
effect. Negative (-) settings will invert
the phase.
Flngr Bal
D100:0W–
D0:100W
Adjust the volume balance between
the direct sound and the flanger
sound. With a setting of “D100:0W,”
only the direct sound will be output.
With a setting of “D0:100W,” only
the flanger sound will be output.
Delay Time 0.1–500.0 ms
Adjust the time delay from when the
direct sound begins until the delay
sound is heard.
Delay Feedback -98– +98%
Adjust the proportion (%) of the delay
sound that is fed back into the delay
input. Negative (-) settings will invert
the phase.
Delay HF Damp
200–8000 Hz,
BYPASS
Adjust the frequency above which
delayed sound fed back to the delay
input will be cut. If you do not want to
cut the high frequencies of the delay
feedback, set this parameter to
BYPASS.
Delay Bal
D100:0W–
D0:100W
Adjust the volume balance between
the flanger sound that is sent through
the delay and the flanger sound that is
not sent through the delay. With a
setting of “D100:0W,” only the
flanger sound will be output. With a
setting of “D0:100W,” only the
flanger sound that is sent through the
delay will be output.
Level 0–127 Adjust the output level.
Assignable Parameters
MFX Control Chorus Bal, Flngr Bal, Chorus Rate, Flngr Rate
Parameter
Value Description
Chorus PreDly
0.0–100.0 ms
Adjust the time delay from when the
direct sound begins until the chorus
sound is heard.
Chorus Rate 0.05–10.00 Hz
Adjust the modulation speed of the
chorus effect.
Parameter
Value Description
