Effect/Parameter List
112: *OVDRV → DLY
(OVERDRIVE → DELAY)
This effect connects an overdrive and a delay in series.
113: *DIST → CHO
(DISTORTION → CHORUS)
This effect connects distortion and chorus in series. The
parameters are essentially the same as “110:
OD → CHORUS,” with the exception of the following two.
OD Drive → Dst Drive (Specify the amount of distortion.)
OD Pan → Dist Pan (Specify the stereo location of the
distortion sound.)
114: *DIST → FLNGR
(DISTORTION → FLANGER)
This effect connects distortion and flanger in series. The
parameters are essentially the same as in “111:
OD → FLANGER,” with the exception of the following two.
OD Drive → Dst Drive (Specify the amount of distortion.)
OD Pan → Dist Pan (Specify the stereo location of the
distortion sound.)
115: *DIST → DELAY
(DISTORTION → DELAY)
This effect connects distortion and delay in series. The
parameters are essentially the same as in “112:
OD → DELAY,” with the exception of the following two.
OD Drive → Dst Drive (Specify the amount of distortion.)
OD Pan → Dist Pan (Specify the stereo location of the distortion
sound.)
116: *ENH → CHORUS
(ENHANCER → CHORUS)
This effect connects an enhancer and a chorus in series.
117: *ENH → FLANGR
(ENHANCER → CHORUS)
This effect connects an enhancer and a flanger in series.
Assignable Parameters
MFX Control
Delay Bal, OD Drive
Parameter Value Description
OD Drive
0–127
Adjust the degree of overdrive
distortion. The volume will change
together with the degree of distortion.
OD Pan L64–0–63R
Adjust the stereo location of the
overdrive sound. L64 is far left, 0 is
center, and 63R is far right.
Delay Time 0.1–500.0 ms
Adjust the time delay from when the
direct sound begins until the delay
sound is heard.
Delay Feedback -98– +98%
Adjust the proportion (%) of the delay
sound that is fed back into the effect.
Negative (-) settings will invert the
phase.
Delay HF Damp
200–8000 Hz,
BYPASS
Adjust the frequency above which
delayed sound fed back to the effect
will be cut. If you do not want to cut the
high frequencies of the feedback, set
this parameter to BYPASS.
Delay Bal
D100:0W–
D0:100W
Adjust the volume balance between
the overdrive sound that is sent
through the delay and the overdrive
sound that is not sent through the
delay. With a setting of “D100:0W,”
only the overdrive sound will be
output. With a setting of “D0:100W,”
only the overdrive sound that is sent
through the delay will be output.
Level 0–127 Adjust the output level.
Assignable Parameters
MFX Control
Chorus Bal, Chorus Rate, Enhancer Sens
Parameter Value Description
Enhancer Sens
0–127 Adjust the sensitivity of the enhancer.
Enhancer Mix 0–127
Adjust the ratio with which the
overtones generated by the enhancer
are combined with the direct sound.
Chorus PreDly 0.0–100.0 ms
Adjust the time delay from when the
direct sound begins until the chorus
sound is heard.
Chorus Rate 0.05–10.00 Hz
Adjust the modulation speed of the
chorus effect.
Chorus Depth 0–127
Adjust the modulation depth of the
chorus effect.
Chorus Bal
D100:0W–
D0:100W
Adjust the volume balance between
the enhancer sound that is sent
through the chorus and the enhancer
sound that is not sent through the
chorus. With a setting of “D100:0W,”
only the enhancer sound will be
output. With a setting of “D0:100W,”
only the enhancer sound that is sent
through the chorus will be output.
Level 0–127 Adjust the output level.
Assignable Parameters
MFX Control
Flngr Bal, Flngr Rate, Enhancer Sens
Parameter
Value Description
Enhancer Sens
0–127 Adjust the sensitivity of the enhancer.
Enhancer Mix 0–127
Adjust the ratio with which the
overtones generated by the enhancer
are combined with the direct sound.
Flngr PreDly 0.0–100.0 ms
Adjust the time delay from when the
direct sound begins until the flanger
sound is heard.
Flngr Rate 0.05–10.00 Hz
Adjust the modulation speed of the
flanger effect.
Flngr Depth 0–127
Adjust the modulation depth of the
flanger effect.
Flngr Fbk -98– +98%
Adjust the proportion (%) of the
flanger sound that is fed back into the
effect. Negative (-) settings will invert
the phase.
Flngr Bal
D100:0W–
D0:100W
Adjust the volume balance between
the enhancer sound that is sent
through the flanger and the enhancer
sound that is not sent through the
flanger. With a setting of
“D100:0W,” only the enhancer sound
will be output. With a setting of
“D0:100W,” only the enhancer sound
that is sent through the flanger will be
output.
Level 0–127 Adjust the output level.
