182
Effect/Parameter List
109: *GATE REV (GATED REVERB)
Gate Reverb is a special type of reverb in which the
reverberant sound is cut off before its natural length.
110:*OVDRV
→
CHO
(OVERDRIVE
→
CHORUS)
This effect connects an overdrive and a chorus in series.
111: *OVDRV
→
FLN
(OVERDRIVE
→
FLANGER)
This effect connects an overdrive and a flanger in series.
Parameter
Value Description
Type
ROOM1,
ROOM2,
STAGE1,
STAGE2,
HALL1,
HALL2
Select the type of Reverb effect.
ROOM1
: dense reverb with short
decay
ROOM2
: sparse reverb with short
decay
STAGE1
: reverb with greater late
reverberation
STAGE2
: reverb with strong early
reflections
HALL1
: reverb with clear reverberance
HALL2
: reverb with rich reverberance
Pre Delay 0.0–100.0 ms
Adjust the time delay from when the
direct sound begins until the reverb
sound is heard.
Time 0–127
Adjust the time length of
reverberation.
HF Damp
200–8000 Hz,
BYPASS
Adjust the frequency above which the
reverberant sound will be cut. As the
frequency is set lower, more of the
high frequencies will be cut, resulting
in a softer and more muted
reverberance. If you do not want the
high frequencies to be cut, set this
parameter to BYPASS.
Low Gain -15– +15 dB
Adjust the gain of the low frequency
range.
Positive (+) settings will emphasize
(boost) the low frequency range.
High Gain -15– +15 dB
Adjust the gain of the high frequency
range.
Positive (+) settings will emphasize
(boost) the high frequency range.
Balance
D100:0W–
D0:100W
Adjust the volume balance between
the direct sound and the reverb sound.
With a setting of D100:0W only the
direct sound will be output, and with a
setting of D0:100W only the reverb
sound will be output.
Level 0–127 Adjust the output level.
Assignable Parameters
MFX Control
Balance
Parameter
Value Description
Type
NORMAL,
REVERSE,
SWEEP1,
SWEEP2
Select the type of reverb.
NORMAL
: conventional gate reverb
REVERSE
: backwards reverb
SWEEP1
: the reverberant sound moves
from right to left
SWEEP2
: the reverberant sound moves
from left to right
Pre Delay 0.0–100.0 ms
Adjust the time delay from when the
direct sound begins until the reverb
sound is heard.
Time 5–500 ms
Adjust the time from when the reverb is
heard until when it disappears.
Low Gain -15– +15 dB
Adjust the gain of the low frequency
range.
Positive (+) settings will emphasize
(boost) the low frequency range.
High Gain -15– +15 dB
Adjust the gain of the high frequency
range.
Positive (+) settings will emphasize
(boost) the high frequency range.
Balance
D100:0W–
D0:100W
Adjust the volume balance between
the direct sound and the reverb sound.
With a setting of D100:0W only the
direct sound will be output, and with a
setting of D0:100W only the reverb
sound will be output.
Level 0–127 Adjust the output level.
Assignable Parameters
MFX Control
Chorus Bal, Chorus Rate, OD Drive
Parameter Value Description
OD Drive
0–127
Adjust the degree of overdrive
distortion. The volume will change
together with the degree of distortion.
OD Pan L64–0–63R
Adjust the stereo location of the
overdrive sound. L64 is far left, 0 is
center, and 63R is far right.
Chorus PreDly 0.0–100.0 ms
Adjust the time delay from when the
direct sound begins until the chorus
sound is heard.
Chorus Rate 0.05–10.00 Hz
Adjust the modulation speed of the
chorus effect.
Chorus Depth 0–127
Adjust the modulation depth of the
chorus effect.
Chorus Bal
D100:0W–
D0:100W
Adjust the volume balance between
the overdrive sound that is sent
through the chorus and the overdrive
sound that is not sent through the
chorus. With a setting of “D100:0W,”
only the overdrive sound will be
output. With a setting of “D0:100W,”
only the overdrive sound that is sent
through the chorus will be output.
Level 0–127 Adjust the output level.
Assignable Parameters
MFX Control
Flngr Bal, Flngr Rate, OD Drive
Parameter
Value Description
OD Drive 0–127
Adjust the degree of overdrive
distortion. The volume will change
together with the degree of distortion.
OD Pan L64–0–63R
Adjust the stereo location of the
overdrive sound. L64 is far left, 0 is
center, and 63R is far right.
Flngr PreDly 0.0–100.0 ms
Adjust the time delay from when the
direct sound begins until the flanger
sound is heard.
Flngr Rate 0.05–10.00 Hz
Adjust the modulation speed of the
flanger effect.
Flngr Depth 0–127
Adjust the modulation depth of the
flanger effect.
Flngr Fbk -98– +98%
Adjust the proportion (%) of the
flanger sound that is fed back into the
effect. Negative (-) settings will invert
the phase.
Flngr Bal
D100:0W–
D0:100W
Adjust the volume balance between
the overdrive sound that is sent
through the flanger and the overdrive
sound that is not sent through the
flanger. With a setting of
“D100:0W,” only the overdrive
sound will be output. With a setting of
“D0:100W,” only the overdrive
sound that is sent through the flanger
will be output.
Level 0–127 Adjust the output level.
RD-700GX_e.book 182 ページ ２００８年２月１３日 水曜日 午後５時４９分
