Roland RD-700GX User Manual

181
Effect/Parameter List
106: *2V PCH SFT
(2 VOICE PITCH SHIFTER)
A Pitch Shifter shifts the pitch of the direct sound. This 2-voice
pitch shifter has two pitch shifters, and can add two pitch
shifted sounds to the direct sound.
107: *FBK P.SFT
(FEEDBACK PITCH SHIFTER)
This pitch shifter allows the pitch shifted sound to be fed back
into the effect.
108: *REVERB
The Reverb effect adds reverberation to the sound, simulating
an acoustic space.
Acceleration
0–15
This parameter adjusts the time over
which the Delay Time will change from
the current setting to a newly specified
setting. The rate of change for the
Delay Time directly affects the rate of
pitch change.
HF Damp
200–8000 Hz,
BYPASS
Adjust the frequency above which
sound fed back to the effect will be
cut. If you do not want to cut the high
frequencies of the feedback, set this
parameter to BYPASS.
Pan L64–0–63R
Adjust the stereo location of the delay
sound. L64 is far left, 0 is center, and
63R is far right.
Low Gain -15– +15 dB
Adjust the gain of the low frequency
range.
Positive (+) settings will emphasize
(boost) the low frequency range.
High Gain -15– +15 dB
Adjust the gain of the high frequency
range.
Positive (+) settings will emphasize
(boost) the high frequency range.
Balance
D100:0W–
D0:100W
Adjust the volume balance between
the direct sound and the delay sound.
With a setting of D100:0W only the
direct sound will be output, and with a
setting of D0:100W only the delay
sound will be output.
Level 0–127 Adjust the output level.
Assignable Parameters
MFX Control
Balance, Coarse A, Coarse B
Parameter
Value Description
Mode
1, 2, 3, 4, 5
Higher settings of this parameter will
result in slower response, but steadier
pitch.
Coarse A
-24– +12
semitone
Adjust the pitch of Pitch Shift A in
semitone steps (-2–+1 octaves).
Coarse B
-24– +12
semitone
Adjust the pitch of Pitch Shift B in
semitone steps (-2–+1 octaves).
Fine A
-100– +100
cent
Make fine adjustments to the pitch of
Pitch Shift A in 2-cent steps (-100–
+100 cents).
One cent is 1/100th of a semitone.
Fine B
-100– +100
cent
Make fine adjustments to the pitch of
Pitch Shift B in 2-cent steps (-100–
+100 cents).
One cent is 1/100th of a semitone.
Pre Delay A 0.0–500.0 ms
Adjust the time delay from when the
direct sound begins until the Pitch Shift
A sound is heard.
Pre Delay B 0.0–500.0 ms
Adjust the time delay from when the
direct sound begins until the Pitch Shift
A sound is heard.
Pan A L64–0–63R
Adjust the stereo location of the Pitch
Shift A sound. L64 is far left, 0 is
center, and 63R is far right.
Pan B L64–0–63R
Adjust the stereo location of the Pitch
Shift B sound. L64 is far left, 0 is
center, and 63R is far right.
Parameter
Value Description
Level Bal
A100:0B–
A0:100B
Adjust the volume balance between
the Pitch Shift A and Pitch Shift B
sounds.
When set to A100:0B, only the sound
of Pitch Shift A is output; when set to
A0:100B, only the sound of Pitch Shift
B is output.
Balance
D100:0W–
D0:100W
Adjust the volume balance between
the direct sound and the pitch shift
sound. With a setting of D100:0W
only the direct sound will be output,
and with a setting of D0:100W only
the pitch shift sound will be output.
Level 0–127 Adjust the output level.
Assignable Parameters
MFX Control
Balance, Coarse, Feedback
Parameter
Value Description
Mode 1, 2, 3, 4, 5
Higher settings of this parameter will
result in slower response, but steadier
pitch.
Coarse
-24– +12
semitone
Adjust the pitch of the pitch shifted
sound in semitone steps (-2–+1
octaves).
Fine
-100– +100
cent
Make fine adjustments to the pitch of
the pitch shifted sound in 2-cent steps
(one cent is 1/100th of a semi tone).
Pre Delay 0.0–500.0 ms
Adjust the time delay from when the
direct sound begins until the pitch
shifted sound is heard.
Feedback -98– +98%
Adjust the proportion (%) of the
processed sound that is fed back into
the effect. Negative (-) settings will
invert the phase.
Pan L64–0–63R
Adjust the stereo location of the pitch
shifted sound. L64 is far left, 0 is
center, and 63R is far right.
Low Gain -15– +15 dB
Adjust the gain of the low frequency
range.
Positive (+) settings will emphasize
(boost) the low frequency range.
High Gain -15– +15 dB
Adjust the gain of the high frequency
range.
Positive (+) settings will emphasize
(boost) the high frequency range.
Balance
D100:0W–
D0:100W
Adjust the volume balance between
the direct sound and the pitch shift
sound. With a setting of D100:0W
only the direct sound will be output,
and with a setting of D0:100W only
the pitch shift sound will be output.
Level 0–127 Adjust the output level.
Assignable Parameters
MFX Control Time, Type, Balance
Parameter
Value Description
RD-700GX_e.book 181 ページ ２００８年２月１３日 水曜日 午後５時４９分
