180
Effect/Parameter List
103: *TRIPLE DLY (TRIPLE TAP DELAY)
The Triple Tap Delay produces three delay sounds; center, left
and right.
Delay C, Delay L and Delay R parameters can be set as a
note-value of a tempo. In this case, specify the value of the
desired note.
104:*QUAD.DELAY
(QUADRUPLE TAP DELAY)
The Quadruple Tap Delay has four delays.
The stereo location of each delay sound is as follows.
Delay 1–4 parameters can be set as a note-value of a tempo.
In this case, specify the value of the desired note.
105: *T-CTRL DLY
(TIME CONTROL DELAY)
When the Effects MFX Control setting in Edit mode set to
“Delay,” you can use MULTI EFFECTS [CONTROL] knob to
make changes in the delay time and pitch in real time.
Lengthening the delay will lower the pitch, and shortening it
will raise the pitch.
HF Damp
200–8000 Hz,
BYPASS
Adjust the frequency above which
sound fed back to the effect will be
cut. If you do not want to cut the high
frequencies of the feedback, set this
parameter to BYPASS.
Rate
0.05–10.00 Hz
Adjust the speed of the modulation.
Depth 0–127 Adjust the depth of the modulation.
Phase 0–180 degree
Adjust the spatial spread of the sound.
Low Gain -15– +15 dB
Adjust the gain of the low frequency
range.
Positive (+) settings will emphasize
(boost) the low frequency range.
High Gain -15– +15 dB
Adjust the gain of the high frequency
range.
Positive (+) settings will emphasize
(boost) the high frequency range.
Balance
D100:0W–
D0:100W
Adjust the volume balance between
the direct sound and the modulation
delay sound. With a setting of
D100:0W only the direct sound will
be output, and with a setting of
D0:100W only the modulation delay
sound will be output.
Level 0–127 Adjust the output level.
Assignable Parameters
MFX Control
Balance
Parameter
Value Description
Dly Left
200–1000 ms,
note (*2)
Adjust the time delay from the direct
sound until when the left delay sound
is heard.
Dly Right
200–1000 ms,
note (*2)
Adjust the time delay from the direct
sound until when the right delay sound
is heard.
Dly Center
200–1000 ms,
note (*2)
Adjust the time delay from the direct
sound until when the center delay
sound is heard.
Feedback -98– +98%
Adjust the proportion (%) of the delay
sound that is fed back into the effect.
Negative (-) settings will invert the
phase.
HF Damp
200–8000 Hz,
BYPASS
Adjust the frequency above which
sound fed back to the effect will be
cut. If you do not want to cut the high
frequencies of the feedback, set this
parameter to BYPASS.
Left Level 0–127
Adjust the volume of the left delay
sound.
Right Level 0–127
Adjust the volume of the right delay
sound.
Center Level 0–127
Adjust the volume of the center delay
sound.
Low Gain -15– +15 dB
Adjust the gain of the low frequency
range.
Positive (+) settings will emphasize
(boost) the low frequency range.
High Gain -15– +15 dB
Adjust the gain of the high frequency
range.
Positive (+) settings will emphasize
(boost) the high frequency range.
Balance
D100:0W–
D0:100W
Adjust the volume balance between
the direct sound and the delay sound.
With a setting of D100:0W only the
direct sound will be output, and with a
setting of D0:100W only the delay
sound will be output.
Level 0–127 Adjust the output level.
Parameter
Value Description
Assignable Parameters
MFX Control
Balance
Parameter
Value Description
Dly1 Time
200–1000 ms,
note
Adjust the time delay from the direct
sound until when delay 1 sound is
heard.
Dly2 Time
200–1000 ms,
note
Adjust the time delay from the direct
sound until when delay 2 sound is
heard.
Dly3 Time
200–1000 ms,
note
Adjust the time delay from the direct
sound until when delay 3 sound is
heard.
Dly4 Time
200–1000 ms,
note
Adjust the time delay from the direct
sound until when delay 4 sound is
heard.
Level 1 0–127 Adjust the volume of delay 1 sound.
Level 2 0–127 Adjust the volume of delay 2 sound.
Level 3 0–127 Adjust the volume of delay 3 sound.
Level 4 0–127 Adjust the volume of delay 4 sound.
Feedback -98– +98%
Adjust the proportion (%) of the delay
sound that is fed back into the effect.
Negative (-) settings will invert the
phase.
HF Damp
200–8000 Hz,
BYPASS
Adjust the frequency above which
sound fed back to the effect will be
cut. If you do not want to cut the high
frequencies of the feedback, set this
parameter to BYPASS.
Balance
D100:0W–
D0:100W
Adjust the volume balance between
the direct sound and the delay sound.
With a setting of D100:0W only the
direct sound will be output, and with a
setting of D0:100W only the delay
sound will be output.
Level 0–127 Adjust the output level.
Assignable Parameters
MFX Control
Delay, Balance
Parameter Value Description
Delay
200–1000 ms
Adjust the time delay from the direct
sound until when each delay sound is
heard.
Feedback -98– +98%
Adjust the proportion (%) of the delay
sound that is fed back into the effect.
Negative (-) settings will invert the
phase.
