179
Effect/Parameter List
100: *STEP FLNGR (STEP FLANGER)
The Step Flanger effect is a flanger in which the flanger pitch
changes in steps.
101: *STEREO DLY (STEREO DELAY)
102: *MOD DELAY
(MODULATION DELAY)
This effect adds modulation to the delayed sound, producing
an effect similar to a flanger.
Feedback
-98– +98%
Adjust the proportion (%) of the
processed sound that is returned (fed
back) into the input. Positive (+)
settings will return the sound in phase,
and negative (-) settings will return the
sound in reverse phase.
The effect becomes more prominent as
the value is increased.
Low Gain -15– +15 dB
Adjust the gain of the low frequency
range.
Positive (+) settings will emphasize
(boost) the low frequency range.
High Gain -15– +15 dB
Adjust the gain of the high frequency
range.
Positive (+) settings will emphasize
(boost) the high frequency range.
Balance
D100:0W–
D0:100W
Adjust the volume balance between
the direct sound and the flanger
sound. With a setting of D100:0W
only the direct sound will be output,
and with a setting of D0:100W only
the flanger sound will be output.
Level 0–127 Adjust the output level.
Assignable Parameters
MFX Control
Step Rate, Feedback, Balance
Parameter
Value Description
Pre Delay
0.0–100.0 ms
Adjust the time delay from when the
direct sound begins until the flanger
sound is heard.
Rate
0.05–10.00 Hz
Adjust the rate of modulation.
Depth 0–127 Adjust the depth of modulation.
Feedback -98– +98%
Adjust the proportion (%) of the
flanger sound that is returned (fed
back) into the input. Negative (-)
settings will invert the phase.
The effect becomes more prominent as
the value is increased.
Step Rate
0.10–20.00
Hz, note (*2)
Adjust the rate (period) of pitch
change.
Step Rate parameter can be set as a
note-value of a tempo. In this case,
specify the value of the desired note.
Phase 0–180 degree Adjust the spatial spread of the sound.
Low Gain -15– +15 dB
Adjust the gain of the low frequency
range.
Positive (+) settings will emphasize
(boost) the low frequency range.
High Gain -15– +15 dB
Adjust the gain of the high frequency
range.
Positive (+) settings will emphasize
(boost) the high frequency range.
Balance
D100:0W–
D0:100W
Adjust the volume balance between
the direct sound and the flanger
sound. With a setting of D100:0W
only the direct sound will be output,
and with a setting of D0:100W only
the chorus sound will be output.
Level 0–127 Adjust the output level.
Assignable Parameters
MFX Control
Balance
Parameter
Value Description
Parameter Value Description
Feedback mode
NORMAL,
CROSS
Select the way in which delay sound is
fed back into the effect.
NORMAL
: The left delay sound will be
fed back into the left delay, and the
right delay sound into the right delay.
CROSS
: The left delay sound will be
fed back into the right delay, and the
right delay sound into the left delay.
Delay Left 0.1–500.0 ms
Adjust the time from the direct sound
until when the left delay sound is
heard.
Delay Right 0.1–500.0 ms
Adjust the time from the direct sound
until when the right delay sound is
heard.
Phase Left
NORMAL,
INVERT
Select the phase of the left delay
sound.
NORMAL
: Phase is not changed.
INVERT
: Phase is inverted.
Phase Right
NORMAL,
INVERT
Select the phase of the right delay
sound.
NORMAL
: Phase is not changed.
INVERT
: Phase is inverted.
Feedback -98– +98%
Adjust the proportion (%) of the delay
sound that is fed back into the effect.
Negative (-) settings will invert the
phase.
HF Damp
200–8000 Hz,
BYPASS
Adjust the frequency above which
sound fed back to the effect will be
cut. If you do not want to cut the high
frequencies of the feedback, set this
parameter to BYPASS.
Low Gain -15– +15 dB
Adjust the gain of the low frequency
range.
Positive (+) settings will emphasize
(boost) the low frequency range.
High Gain -15– +15 dB
Adjust the gain of the high frequency
range.
Positive (+) settings will emphasize
(boost) the high frequency range.
Balance
D100:0W–
D0:100W
Adjust the volume balance between
the direct sound and the delay sound.
With a setting of D100:0W only the
direct sound will be output, and with a
setting of D0:100W only the delay
sound will be output.
Level 0–127 Adjust the output level.
Assignable Parameters
MFX Control
Rate, Balance
Parameter
Value Description
Feedback mode
NORMAL,
CROSS
Select the way in which delay sound is
fed back into the effect.
NORMAL
: The left delay sound will be
fed back into the left delay, and the
right delay sound into the right delay.
CROSS
: The left delay sound will be
fed back into the right delay, and the
right delay sound into the left delay.
Delay Left 0.1–500.0 ms
Adjust the time from the direct sound
until when the left delay sound is
heard.
Delay Right 0.1–500.0 ms
Adjust the time from the direct sound
until when the right delay sound is
heard.
Feedback -98– +98%
Adjust the proportion (%) of the delay
sound that is fed back into the effect.
Negative (-) settings will invert the
phase.
RD-700GX_e.book 179 ページ ２００８年２月１３日 水曜日 午後５時４９分
