178
Effect/Parameter List
96: *TREMOL CHO (TREMOLO CHORUS)
Tremolo Chorus is a chorus effect with added Tremolo (cyclic
modulation of volume).
97: *SPACE-D
Space-D is a multiple chorus that applies two-phase
modulation in stereo. It gives no impression of modulation, but
produces a transparent chorus effect.
98: *STEREO CHO (STEREO CHORUS)
This is a stereo chorus. A filter is provided so that you can
adjust the timbre of the chorus sound.
99: *ST.FLANGER (STEREO FLANGER)
This is a stereo flanger. (The LFO has the same phase for left
and right.) It produces a metallic resonance that rises and falls
like a jet airplane taking off or landing. A filter is provided so
that you can adjust the timbre of the flanged sound.
Pan Deviation
0–20
Adjust the difference in stereo location
between each chorus sound. With a
setting of 0, all chorus sounds will be
in the center. With a setting of 20,
each chorus sound will be spaced at
60 degree intervals relative to the
center.
Balance
D100:0W–
D0:100W
Adjust the volume balance between
the direct sound and the chorus sound.
With a setting of D100:0W only the
direct sound will be output, and with a
setting of D0:100W only the chorus
sound will be output.
Level 0–127 Adjust the output level.
Assignable Parameters
MFX Control
Chorus Rate, Treml Rate, Balance
Parameter
Value Description
Pre Delay
0.0–100.0 ms
Adjust the time delay from when the
direct sound begins until the chorus
sound is heard.
Chorus Rate
0.05–10.00 Hz
Adjust the modulation speed of the
chorus effect.
Chorus Depth 0–127
Adjust the modulation depth of the
chorus effect.
Treml Rate 0.05–10.00 Hz
Adjust the modulation speed of the
tremolo effect.
Treml
Separation
0–127 Adjust the spread of the tremolo effect.
Treml Phase 0–180 degree Adjust the spread of the tremolo effect.
Balance
D100:0W–
D0:100W
Adjust the volume balance between
the direct sound and the tremolo
chorus sound. With a setting of
D100:0W only the direct sound will
be output, and with a setting of
D0:100W only the tremolo chorus
sound will be output.
Level 0–127 Adjust the output level.
Assignable Parameters
MFX Control
Rate, Balance
Parameter
Value Description
Pre Delay
0.0–100.0 ms
Adjust the time delay from when the
direct sound begins until the
processed sound is heard.
Rate
0.05–10.00 Hz
Adjust the rate of modulation.
Depth 0–127 Adjust the depth of modulation.
Phase 0–180 degree Adjust the spatial spread of the sound.
Low Gain -15– +15 dB
Adjust the gain of the low frequency
range.
Positive (+) settings will emphasize
(boost) the low frequency range.
High Gain -15– +15 dB
Adjust the gain of the high frequency
range.
Positive (+) settings will emphasize
(boost) the high frequency range.
Parameter
Value Description
Balance
D100:0W–
D0:100W
Adjust the volume balance between
the direct sound and the chorus sound.
With a setting of D100:0W only the
direct sound will be output, and with a
setting of D0:100W only the chorus
sound will be output.
Level 0–127 Adjust the output level.
Assignable Parameters
MFX Control
Rate, Balance
Parameter
Value Description
Filter Type
OFF,
LPF,
HPF
Select the type of filter.
OFF
: a filter will not be used
LPF
: cut the frequency range above the
cutoff frequency
HPF
: cut the frequency range below
the cutoff frequency
Cutoff Freq 200–8000 Hz Adjust the basic frequency of the filter.
Pre Delay 0.0–100.0 ms
Adjust the time delay from when the
direct sound begins until the
processed sound is heard.
Rate
0.05–10.00 Hz
Adjust the rate of modulation.
Depth 0–127 Adjust the depth of modulation.
Phase 0–180 degree Adjust the spatial spread of the sound.
Low Gain -15– +15 dB
Adjust the gain of the low frequency
range.
Positive (+) settings will emphasize
(boost) the low frequency range.
High Gain -15– +15 dB
Adjust the gain of the high frequency
range.
Positive (+) settings will emphasize
(boost) the high frequency range.
Balance
D100:0W–
D0:100W
Adjust the volume balance between
the direct sound and the chorus sound.
With a setting of D100:0W only the
direct sound will be output, and with a
setting of D0:100W only the chorus
sound will be output.
Level 0–127 Adjust the output level.
Assignable Parameters
MFX Control
Rate, Feedback, Balance
Parameter
Value Description
Filter Type
OFF,
LPF,
HPF
Select the type of filter.
OFF
: a filter will not be used
LPF
: cut the frequency range above the
cutoff frequency
HPF
: cut the frequency range below
the cutoff frequency
Cutoff Freq 200–8000 Hz Adjust the basic frequency of the filter.
Pre Delay 0.0–100.0 ms
Adjust the time delay from when the
direct sound begins until the flanger
sound is heard.
Rate
0.05–10.00 Hz
Adjust the rate of modulation.
Depth 0–127 Adjust the depth of modulation.
Phase 0–180 degree Adjust the spatial spread of the sound.
Parameter
Value Description
RD-700GX_e.book 178 ページ ２００８年２月１３日 水曜日 午後５時４９分
