177
Effect/Parameter List
92: *ROTARY
The Rotary effect simulates the sound of the rotary speakers
often used with the electric organs of the past. Since the
movement of the high range and low range rotors can be set
independently, the unique type of modulation characteristic of
these speakers can be simulated quite closely. This effect is
most suitable for electric organ Patches.
93: *COMPRESSOR
The Compressor flattens out high levels and boosts low levels,
smoothing out unevenness in volume.
94: *LIMITER
The Limiter compresses signals that exceed a specified volume
level, preventing distortion from occurring.
95: *HEXA-CHO (HEXA-CHORUS)
Hexa-chorus uses a six-phase chorus (six layers of chorused
sound) to give richness and spatial spread to the sound.
Peak
0–127
Adjust the amount of the wah effect
that will occur in the area of the
frequency. Lower settings will cause
the effect to be applied in a broad
area around the frequency. Higher
settings will cause the effect to be
applied in a more narrow range.
Level 0–127 Adjust the output level.
Assignable Parameters
MFX Control
Speed, Hi Fast Rate, Lo Fast Rate, Separation
Parameter
Value Description
Hi Slow Rate
0.05–10.00 Hz
Adjust the slow speed (SLOW) of the
high frequency rotor.
Lo Slow Rate 0.05–10.00 Hz
Adjust the slow speed (SLOW) of the
low frequency rotor.
Hi Fast Rate 0.05–10.00 Hz
Adjust the fast speed (FAST) of the
high frequency rotor.
Lo Fast Rate 0.05–10.00 Hz
Adjust the fast speed (FAST) of the low
frequency rotor.
Speed SLOW, FAST
Simultaneously switch the rotational
speed of the low frequency rotor and
high frequency rotor.
SLOW
: Slow down the rotation to the
specified speed (the Low Slow/Hi
Slow values).
FAST
: Speed up the rotation to the
specified speed (the Low Fast/Hi Fast
values).
Hi Acceleration 0–15
Adjust the time it takes the high
frequency rotor to reach the newly
selected speed when switching from
fast to slow (or slow to fast) speed.
Lower values will require longer times.
Lo Acceleration 0–15
Adjust the time it takes the low
frequency rotor to reach the newly
selected speed when switching from
fast to slow (or slow to fast) speed.
Lower values will require longer times.
High Level 0–127
Adjust the volume of the high
frequency rotor.
Low Level 0–127
Adjust the volume of the low frequency
rotor.
Separation 0–127
Adjust the spatial dispersion of the
sound.
Level 0–127 Adjust the output level.
Assignable Parameters
MFX Control
Pan, Level
Parameter
Value Description
Sustain 0–127
Adjust the time over which low level
sounds are boosted until they reach
the specified volume.
Attack 0–127
Adjust the attack time of an input
sound.
Parameter
Value Description
Pan
L64–0–63R
Adjust the stereo location of the output
sound. L64 is far left, 0 is center, and
63R is far right.
Post Gain
0, +6, +12,
+18 dB
Adjust the output gain.
Low Gain -15– +15 dB
Adjust the low frequency gain.
Positive (+) settings will emphasize
(boost) the low frequency range.
High Gain -15– +15 dB
Adjust the high frequency gain.
Positive (+) settings will emphasize
(boost) the high frequency range.
Level 0–127 Adjust the output level.
Assignable Parameters
MFX Control
Threshold, Release
Parameter
Value Description
Threshold
0–127
Adjust the volume at which
compression will begin.
Release 0–127
Adjust the time from when the volume
falls below the Threshold Level until
compression is no longer applied.
Ratio
1.5:1, 2:1, 4:1,
100:1
Adjust the compression ratio.
Pan L64–0–63R
Adjust the stereo location of the output
sound. L64 is far left, 0 is center, and
63R is far right.
Post Gain
0, +6, +12,
+18 dB
Adjust the output gain.
Low Gain -15– +15 dB
Adjust the low frequency gain.
Positive (+) settings will emphasize
(boost) the low frequency range.
High Gain -15– +15 dB
Adjust the high frequency gain.
Positive (+) settings will emphasize
(boost) the high frequency range.
Level 0–127 Adjust the output level.
Assignable Parameters
MFX Control
Rate, Balance
Parameter
Value Description
Pre Delay
0.0–100.0 ms
Adjust the time delay from when the
direct sound begins until the chorus
sound is heard.
Rate 0.05–10.00 Hz Adjust the rate of modulation.
Depth 0–127 Adjust the depth of modulation.
Pre Delay Deviat 0–20
Pre Delay determines the time from
when the direct sound begins until the
processed sound is heard. Pre Delay
Deviation adjusts the differences in Pre
Delay between each chorus sound.
Depth Deviation -20– +20
Adjust the difference in modulation
depth between each chorus sound.
The shift between the start of each of
the chorus sounds increases as the
value is increased.
Parameter
Value Description
